HomeIndustrial Automation and ControlSoft StartersAltistart 48Schneider ATS48C48Q | Soft starter for asynchronous motor – ATS48 – 437 A – 230..415 V – 110..355 KW
new-45%

Schneider ATS48C48Q | Soft starter for asynchronous motor – ATS48 – 437 A – 230..415 V – 110..355 KW

Schneider ATS48C48Q | Soft starter for asynchronous motor – ATS48 – 437 A – 230..415 V – 110..355 KW

Original price was: EGP 80,830,578.00.Current price is: EGP 44,456,818.00.
Compare
ATS48C48Q
Brand:

Description

ATS48C48Q | Soft starter for asynchronous motor – ATS48 – 437 A – 230..415 V – 110..355 KW

Schneider ATS48C48Q | Soft Starter Overview

The Schneider ATS48C48Q is a soft starter from the Altistart 48 series, designed for high-performance three-phase asynchronous motors. It ensures smooth acceleration and deceleration, reducing mechanical stress and improving motor longevity.

1. General Specifications

  • Product Name: Schneider ATS48C48Q

  • Series: Altistart 48 (ATS48)

  • Type: Soft Starter for Asynchronous Motors

  • Rated Current: 437A

  • Power Rating: 110 to 355 kW

  • Operating Voltage: 230V to 415V AC

  • Control Supply Voltage: 230V AC

  • Motor Compatibility: Three-phase asynchronous motors

2. Key Features

  • Smooth Motor Start & Stop

  • Integrated Motor Protection

  • Optimized Energy Efficiency

  • Built-in Fault Diagnostics

  • Compact & Space-Saving Design

3. Applications

  • Pumps & Compressors

  • Fans & Blowers

  • Conveyors & Belt Systems

  • Industrial Machines

4. Protection & Safety Features

  • Overload & Overtemperature Protection

  • Phase Loss Detection

  • Voltage Ramp Control

  • Built-in Fault Diagnostics

5. Installation & Maintenance

  • DIN Rail or Panel Mounting

  • Quick & Easy Wiring

  • Minimal Maintenance Required

6. Why Choose ATS48C48Q?

  • High Power Capacity

  • Enhanced Motor Protection

  • Reliable & Durable Design

  • Versatile Industrial Applications

Additional information

brands

Schneider Electric

Specifications

Main
Range of product Altistart 48
Product or component type Soft starter
Product destination Asynchronous motors
Product specific application Heavy duty industry and pumps
Device short name ATS48
Utilisation category AC-53A
Ue power supply voltage 230...415 V - 15...10 %
power supply frequency 50...60 Hz - 5...5 %
Motor power kW 110 kW at 230 V connection in the motor supply line for severe applications 132 kW at 230 V connection in the motor supply line for standard applications 220 kW at 230 V connection to the motor delta terminals for severe applications 220 kW at 400 V connection in the motor supply line for severe applications 250 kW at 230 V connection to the motor delta terminals for standard applications 250 kW at 400 V connection in the motor supply line for standard applications 315 kW at 400 V connection to the motor delta terminals for severe applications 355 kW at 400 V connection to the motor delta terminals for standard applications
Complementary
Device connection To the motor delta terminals In the motor supply line
Protection type Phase failure: line Thermal protection: motor Thermal protection: starter
Standards IEC 60947-4-2
Product certifications CSA GOST DNV TCF UL C-Tick NOM 117 CCC SEPRO
Marking CE
Discrete input number 5
Discrete input type PTC, 750 Ohm at 25 °C (Stop, Run, LI3, LI4) logic, <= 8 mA 4300 Ohm
Discrete input logic Positive logic Stop, Run, LI3, LI4 at State 0: < 5 V and <= 2 mA at State 1: > 11 V, >= 5 mA
Minimum switching current 10 mA at 6 V DC for relay outputs
Discrete output number 2
Discrete output type (LO1) logic output 0 V common configurable (LO2) logic output 0 V common configurable (R1) relay outputs fault relay NO (R2) relay outputs end of starting relay NO (R3) relay outputs motor powered NO
Analogue output type Current output AO: 0-20 mA or 4-20 mA, impedance <500 Ohm
Communication port protocol Modbus
Connector type 1 RJ45
Communication data link Serial
Physical interface RS485 multidrop
Transmission rate 4800, 9600 or 19200 bps
Function available External bypass (optional)
Operating position Vertical +/- 10 degree
Height 670 mm
Width 400 mm
Depth 300 mm
Net weight 51.4 kg
Environment
Electromagnetic compatibility Conducted and radiated emissions level A conforming to IEC 60947-4-2 Damped oscillating waves level 3 conforming to IEC 61000-4-12 Electrostatic discharge level 3 conforming to IEC 61000-4-2 Immunity to electrical transients level 4 conforming to IEC 61000-4-4 Immunity to radiated radio-electrical interference level 3 conforming to IEC 61000-4-3 Voltage/current impulse level 3 conforming to IEC 61000-4-5
Relative humidity 0…95 % without condensation or dripping water conforming to IEC 60068-2-3
Ambient air temperature for operation 40…60 °C (with current derating of 2 % per °C) -10…40 °C (without derating)
Ambient air temperature for storage -25…70 °C
Operating altitude <= 1000 m without derating > 1000...2000 m with current derating of 2.2 % per additional 100 m
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 39 cm
Package 1 Width 60 cm
Package 1 Length 78 cm
Package 1 Weight 53.5 kg
Unit Type of Package 2 P06
Number of Units in Package 2 1
Package 2 Height 75 cm
Package 2 Width 60 cm
Package 2 Length 80 cm
Package 2 Weight 62 kg
Contractual warranty
Warranty 18 months

Main documents

Main documents

Datasheet Download Datasheet
Product datasheet Download
User guide
 Download
Catalogue Download
CAD Files Download

Main documents

Datasheet Download Datasheet
Product datasheet Download
User guide
 Download
Catalogue Download
CAD Files Download
