Schneider LC1E65M7 | Easy TeSys contactor 3P(3 NO) – AC-3 – <= 440 V 65A – 220 V AC coil
High performance under AC-3 motor duty, supporting motors up to 37 kW.
Exceptional durability, with millions of mechanical cycles for long service life.
Reliable switching capacity, ensuring stability even under high inrush currents.
Fast and flexible installation, compatible with both DIN-rail and panel mounting.
Trusted Schneider Electric quality, meeting global electrical safety standards.
Original price was: EGP 61,697.00.EGP 33,317.00Current price is: EGP 33,317.00.
Description
Schneider LC1E65M7 | Easy TeSys contactor 3P(3 NO) – AC-3 – <= 440 V 65A – 220 V AC coil
Description
The Schneider Electric LC1E65M7 is a three-pole contactor from the Easy TeSys series, designed for reliable motor control and switching of industrial loads. It comes with 3 normally-open (3 NO) power contacts and is rated for AC-3 motor duty up to 65 A at 440 V, making it suitable for starting and stopping three-phase induction motors. The device operates with a 220 V AC control coil, allowing seamless integration into standard electrical control circuits. Built with robust mechanical design and high electrical endurance, it ensures dependable performance in harsh industrial environments.
Technical Specifications
Poles: 3P (3 NO power contacts)
Utilization Category: AC-3 / AC-3e
Operational Voltage (Ue): Up to 690 V AC, 50/60 Hz
Rated Operational Current (Ie): 65 A at 440 V AC (AC-3 duty)
Rated Thermal Current (Ith): 80 A at 55°C
Motor Power Rating: Up to approximately 37 kW at 440 V AC
Insulation Voltage (Ui): 690 V (IEC 60947-4-1)
Withstand Short-Time Current: e.g., 520 A for 10 s, 260 A for 60 s
Making Capacity: Approx. 650 A at 440 V AC
Breaking Capacity: Approx. 520 A at 440 V AC
Mechanical Durability: Around 5,000,000 operating cycles
Electrical Durability (AC-3): Around 900,000 operating cycles
Mounting Method: DIN-rail or panel mounting
Terminals: Screw-clamp terminals
Approximate Dimensions: 127 mm height, 75 mm width, 114 mm depth
Approximate Weight: 0.98 kg
Coil Voltage: 220 V AC (50/60 Hz)
Key Features
Suitable for switching and controlling three-phase motors under heavy-duty AC-3 conditions.
Compact and robust design ideal for industrial control panels.
High mechanical and electrical endurance for long-term reliability.
Easy wiring and installation with screw terminals and versatile mounting options.
Fully compliant with international standards to ensure safety and performance.
Typical Applications
Motor control for pumps, fans, compressors, and industrial machinery
HVAC systems and ventilation units
Industrial lighting and resistive load switching
Power distribution and control panels
Automation systems requiring frequent start/stop operations
Additional information
| brand | Schneider Electric |
|---|
Specifications
Specifications
| Range | Easy TeSys |
|---|---|
| Range of product | Easy TeSys Control |
| Product or component type | Contactor |
| Device short name | LC1E |
| Contactor application | Motor control Resistive load |
| Utilisation category | AC-3 AC-3e AC-1 |
| Poles description | 3P |
| [Ue] rated operational voltage | Power circuit: <= 690 V AC 50/60 Hz |
| [Ie] rated operational current | 65 A (at <55 °C) at <= 440 V AC AC-3 for power circuit 65 A (at <55 °C) at <= 440 V AC AC-3e for power circuit 80 A (at <55 °C) at <= 440 V AC AC-1 for power circuit |
| [Uc] control circuit voltage | 220 V AC 50/60 Hz |
| Motor power kW | 18.5 kW at 220/230 V AC 50/60 Hz 30 kW at 380/400 V AC 37 kW at 415/440 V AC 37 kW at 500 V AC 37 kW at 660/690 V AC 37 kW at 660...690 V |
|---|---|
| Pole contact composition | 3 NO |
| [Ith] conventional free air thermal current | 80 A (at 55 °C) for power circuit |
| Irms rated making capacity | 845 A at 440 V AC for power circuit conforming to IEC 60947-4-1 |
| Rated breaking capacity | 552.5 A at 440 V for power circuit conforming to IEC 60947 |
| [Icw] rated short-time withstand current | 520 A 40 °C - 10 s for power circuit 260 A 40 °C - 60 s for power circuit 110 A 40 °C - 600 s for power circuit |
| Associated fuse rating | 10 A gG at <= 690 V coordination type 1 for control circuit conforming to IEC 60947-5-1 125 A gG at <= 690 V coordination type 1 for power circuit |
| Average impedance | 1 mOhm - Ith 80 A 50 Hz for power circuit |
| Power dissipation per pole | 4.2 W AC-3 6.4 W AC-1 |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-4-1 |
| Overvoltage category | III |
| Pollution degree | 3 |
| [Uimp] rated impulse withstand voltage | 6 kV coil not connected to the power circuit conforming to IEC 60947 |
| Mechanical durability | 5000000 cycles |
| Electrical durability | 350000 cycles AC-1 900000 cycles AC-3 |
| Control circuit type | AC at 50/60 Hz |
| Control circuit voltage limits | 0.85...1.1 Uc (-5…55 °C):operational 50/60 Hz 0.3...0.6 Uc (-5…55 °C):drop-out 50/60 Hz |
| Inrush power in VA | 160 VA 50 Hz cos phi 0.75 (at 20 °C) 140 VA 60 Hz cos phi 0.75 (at 20 °C) |
| Hold-in power consumption in VA | 15 VA 50 Hz cos phi 0.3 (at 20 °C) 13 VA 60 Hz cos phi 0.3 (at 20 °C) |
| Heat dissipation | 6…10 W for control circuit |
| Operating time | 20...26 ms on closing 8...12 ms on opening |
| Maximum operating rate | 1200 cyc/h 60 °C |
| Connections - terminals | Power circuit: screw clamp terminals 1 2.5…25 mm² - cable stiffness: flexible without cable end Power circuit: screw clamp terminals 2 2.5…10 mm² - cable stiffness: flexible without cable end Power circuit: screw clamp terminals 1 2.5…25 mm² - cable stiffness: flexible with cable end Power circuit: screw clamp terminals 2 2.5…16 mm² - cable stiffness: flexible with cable end Power circuit: screw clamp terminals 1 2.5…25 mm² - cable stiffness: solid without cable end Power circuit: screw clamp terminals 2 2.5…16 mm² - cable stiffness: solid without cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: solid without cable end Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid without cable end |
| Tightening torque | Control circuit: 1.2 N.m Power circuit: 5 N.m |
| Auxiliary contact composition | 1 NO + 1 NC |
| Minimum switching voltage | 17 V for control circuit |
| Minimum switching current | 5 mA for control circuit |
| Insulation resistance | > 10 MOhm for control circuit |
| Non-overlap time | 1.5 ms on energisation guaranteed between NC and NO contact 1.5 ms on de-energisation guaranteed between NC and NO contact |
| Mounting support | DIN rail Plate |
| Standards | IEC 60947-1 IEC 60947-4-1 IEC 60947-5-1 |
|---|---|
| Product certifications | EAC CE |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Protective treatment | TH (pollution degree 3) conforming to IEC 60068-2-30 test Db |
| Permissible ambient air temperature around the device | -20…70 °C at Uc -60…80 °C storage -5…55 °C operation |
| Operating altitude | 3000 m without derating |
| Fire resistance | 850 °C conforming to IEC 60695-2-1 |
| Mechanical robustness | Vibrations contactor open (1.5 Gn, 5...300 Hz) Vibrations contactor closed (3 Gn, 5...300 Hz) Shocks contactor open (6 Gn for 11 ms) Shocks contactor closed (7 Gn for 11 ms) |
| Height | 127 mm |
| Width | 75 mm |
| Depth | 114 mm |
| Net weight | 0.98 kg |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.500 cm |
| Package 1 Width | 12.800 cm |
| Package 1 Length | 13.200 cm |
| Package 1 Weight | 976.000 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 9 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 9.154 kg |
| Warranty (in months) | 18 |
|---|
