Schneider ISM50320 | OptiLine 45 – screed floor box – without modules
Ultimate Customization: Supplied module-free, offering unparalleled flexibility to mix and match power, data, and media modules to precisely fit the user’s current and future infrastructure needs.
Seamless Integration: Provides a flush-mount installation, ensuring the floor box is discreet, maintains the integrity of the room’s aesthetics, and eliminates tripping hazards caused by visible cabling.
Robust Construction: Built to be installed directly into the concrete screed, ensuring high mechanical strength and durability to withstand typical floor loads in commercial settings.
Original price was: EGP 61,959.00.EGP 47,832.00Current price is: EGP 47,832.00.
Description
Schneider ISM50320 | OptiLine 45 – screed floor box – without modules
Description
The Schneider Electric ISM50320 is an essential component of the OptiLine 45 range, designed as a robust screed floor box intended for direct installation within concrete floors or beneath raised access flooring systems. It serves as a centralized, hidden access point for electrical power, data, and communication services in commercial and office environments.
This particular model comes without functional modules, offering the empty housing and frame. This design provides maximum flexibility, allowing installers and end-users to populate the box with the necessary OptiLine 45 power outlets, data sockets (e.g., RJ45), and multimedia components tailored to the specific application needs.
Features, Specifications, and Applications
Type: Screed Floor Box / Floor Trunking Outlet.
Capacity: Houses a specific number of OptiLine 45-compliant function modules (modules purchased separately).
Installation: Designed for integration into the floor structure, sitting flush with the finished floor level to maintain aesthetics and safety.
Application: Ideal for open-plan offices, conference rooms, exhibition halls, and retail spaces where flexible and discreet service access is required away from walls.
Specifications
| Cabling installation system | Floor box |
|---|---|
| product type | Screeded floor box |
| Type of floor | Screeded floor |
| Floor box shape | Square |
| colour | Light grey |
| quantity package 1 / unit | 1 piece |
| fixing mode | Cast-in |
|---|---|
| Number of modules | Without modules |
| product material | PP (polypropylene) |
| Length | 188 mm |
| Height | 75…95 mm |
| Width | 188 mm |
| Standards | 73/23/EEC 93/68/EEC IEC 61084-1:ed. 1, 1991 IEC 61084-2-2:2003 |
|---|---|
| operating temperature | -25…60 °C |
| IP degree of protection | IP20 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 9.500 cm |
| Package 1 Width | 22.500 cm |
| Package 1 Length | 23.000 cm |
| Package 1 Weight | 648.000 g |
| Unit Type of Package 2 | P12 |
| Number of Units in Package 2 | 150 |
| Package 2 Height | 112.000 cm |
| Package 2 Width | 80.000 cm |
| Package 2 Length | 120.000 cm |
| Package 2 Weight | 109.200 kg |
| Warranty (in months) | 18 |
|---|
