Schneider BLRCH200A240B40 | VarPlus Can HDuty Capacitor – 20/24 kvar – 400 V – 50/60Hz
Schneider BLRCH200A240B40 | VarPlus Can HDuty Capacitor – 20/24 kvar – 400 V – 50/60Hz
Original price was: EGP 69,426.00.EGP 5,207.00Current price is: EGP 5,207.00.
Description
Schneider BLRCH200A240B40 | VarPlus Can HDuty Capacitor – 20/24 kvar – 400 V – 50/60Hz
Introduction
The Schneider BLRCH200A240B40 is a high-performance capacitor bank designed to enhance power factor correction in various electrical systems. Known for its advanced features and robust construction, it is essential for improving power quality and operational efficiency in both industrial and commercial applications.
What is the Schneider BLRCH200A240B40?
it is part of Schneider’s renowned BLRCH series, which delivers exceptional performance in power factor correction. This model stands out due to its high-performance capacitors and advanced protection features, making it a reliable choice for managing reactive power in electrical systems. Compared to other models in the BLRCH series, it offers enhanced capabilities suited for more demanding environments.
Key Features of the Schneider BLRCH200A240B40
High-Performance Capacitors
it is equipped with high-quality capacitors that ensure optimal performance and longevity. These capacitors are designed to handle varying loads efficiently, providing stable and reliable power factor correction.
Robust Design
Built to withstand harsh industrial conditions, it features a durable design that ensures long-term reliability. This robustness reduces downtime and maintenance costs, enhancing overall productivity.
Advanced Protection Features
it includes advanced protection mechanisms such as over-voltage and over-temperature protection. These features safeguard the capacitor bank and connected systems, ensuring safe and efficient operation.
Technical Specifications
Power Ratings
it is available in various power ratings to meet different application needs, making it versatile for use in diverse settings.
Voltage and Frequency Range
Supporting a wide range of voltage and frequency inputs, the it offers the flexibility required for different electrical systems.
Physical Dimensions
Designed to fit seamlessly into existing systems, it has compact physical dimensions, making installation straightforward and space-efficient.
Applications of the Schneider BLRCH200A240B40
Industrial Power Factor Correction
In industrial settings, it optimizes power factor correction, reducing energy losses and improving the efficiency of electrical systems.
Commercial Building Applications
For commercial buildings, this capacitor bank ensures efficient power distribution, enhancing the performance and longevity of electrical infrastructure.
Renewable Energy Systems
In renewable energy systems, it helps manage reactive power, ensuring stable and efficient operation of solar and wind power installations.
Advantages of Using Schneider BLRCH200A240B40
Improved Power Quality
By providing effective power factor correction, the BLRCH200A240B40 improves overall power quality, reducing the risk of equipment damage and operational interruptions.
Cost Savings
The enhanced efficiency and reduced energy losses achieved with the BLRCH200A240B40 lead to significant cost savings, making it a cost-effective solution for businesses aiming to optimize their energy usage.
Enhanced System Efficiency
The BLRCH200A240B40 enhances overall system efficiency, ensuring that electrical systems operate at their peak performance with minimal energy waste.
Installation and Setup
Pre-Installation Considerations
Before installing it, it’s important to consider factors such as the installation environment and compatibility with existing systems to ensure a smooth setup process.
Step-by-Step Installation Guide
- Prepare the installation site by ensuring it is clean, dry, and well-ventilated.
- Mount the capacitor bank securely using the appropriate hardware.
- Connect the electrical wiring according to the installation manual’s instructions.
- Configure the settings based on the specific requirements of your application.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range of product | PowerLogic |
|---|---|
| Product or component type | Heavy duty capacitor |
| Network frequency | 50/60 Hz |
| Series name | HDuty |
| Network harmonic content | <= 20 % |
| Electrical parameters | 18.1 kvar 380 V 50 Hz 21.7 kvar 380 V 60 Hz 20 kvar 400 V 50 Hz 24 kvar 400 V 60 Hz 21.5 kvar 415 V 50 Hz 25.8 kvar 415 V 60 Hz |
| Maximum permissible voltage | 1.1 x Un (8 hours over 24 hours) |
| continuous overcurrent capacity | 1.8 x In |
| Rated voltage | 380…415 V AC 50/60 Hz |
| Dielectric losses | < 0.2 W/kvar |
|---|---|
| Power losses | < 0.5 W/kVAr |
| capacitance tolerance | - 5 % to 10 % |
| Voltage test | 2.15 x Un AC between terminals for 10 s <= 660 V - 3 kV AC between terminal and container for 10 s >= 660 V - 6 kV AC between terminal and container for 10 s |
| Inrush current | 250 x In |
| Maximum switching operation per year | 7000 |
| Service life in hours | 130000 h |
| Dielectric material | Metallized polypropylene film with Zn/Al alloy, special resistivity & profile, special edge (wave cut) |
| Impregnation material | Non-PCB dry PUR resin Biodegradable |
| Type of installation | Indoor installation |
| Connections - terminals | ClampTite terminal |
| mounting mode | Upright/horizontal |
| Diameter | 116 mm |
| Height | 242 mm |
| Net weight | 2.5 kg |
| Standards | IEC 60831-1 IEC 60831-2 |
|---|---|
| IP degree of protection | IP20 |
| Operating altitude | 2000 m |
| Temperature class | D |
| Ambient air temperature for operation | -25…55 °C |
| Relative humidity | 95 % |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 19 cm |
| Package 1 Width | 19 cm |
| Package 1 Length | 30.5 cm |
| Package 1 Weight | 2.979 kg |
| Unit Type of Package 2 | S06 |
| Number of Units in Package 2 | 15 |
| Package 2 Height | 74 cm |
| Package 2 Width | 60 cm |
| Package 2 Length | 80 cm |
| Package 2 Weight | 44.685 kg |
| Unit Type of Package 3 | S06 |
| Number of Units in Package 3 | 15 |
| Package 3 Height | 74 cm |
| Package 3 Width | 60 cm |
| Package 3 Length | 80 cm |
| Package 3 Weight | 44.685 kg |
| Warranty | 18 months |
|---|
