Schneider LV510475 | Easypact CVS – CVS100N circuit breaker – 3P/3d
Schneider LV510475 | Easypact CVS – CVS100N circuit breaker – 3P/3d
Original price was: EGP 1,419,300.00.EGP 844,484.00Current price is: EGP 844,484.00.
Description
The Schneider LV510475
it is an essential component in modern electrical systems, providing critical control and protection against electrical faults. Its importance in ensuring the safety and efficiency of electrical installations makes it a valuable asset for various applications, from industrial environments to residential properties.
What is Schneider LV510475?
it is a high-performance circuit breaker from Schneider Electric’s extensive range of electrical protection devices. This circuit breaker is designed to manage significant electrical loads and provide reliable protection against overloads and short circuits.
Technical Specifications
To make the most of it, it’s important to understand its technical specifications:
- Voltage Rating: The LV510475 is rated for voltages up to 690V AC, making it suitable for a wide range of electrical systems.
- Current Rating: It supports a current rating of up to 125A, allowing it to handle substantial electrical currents effectively.
- Breaking Capacity: This circuit breaker features a high breaking capacity, ensuring it can safely interrupt fault currents and protect the system from potential damage.
Applications of Schneider LV510475
Industrial Applications
In industrial settings, it is essential for controlling and protecting machinery and complex electrical systems. Its robust current and voltage ratings make it ideal for factories and manufacturing plants where electrical loads are significant.
Commercial Applications
it is equally valuable in commercial environments, such as office buildings and retail spaces. It ensures the smooth operation of electrical systems, preventing disruptions caused by electrical faults.
Residential Applications
it can also be used in residential properties with higher electrical demands. It provides reliable protection for home electrical systems, ensuring safety and efficiency.
Benefits of Using Schneider LV510475
Reliability
it is engineered to deliver consistent performance under various conditions, offering reliable protection for electrical systems.
Safety
Safety is a crucial aspect of any electrical system. The LV510475’s robust construction ensures it can handle electrical faults without causing damage or hazards.
Efficiency
By maintaining reliable protection and reducing the risk of electrical failures, it contributes to the overall efficiency of electrical systems, helping to reduce energy consumption and operational costs.
Installation Process
Pre-installation Requirements
Before installing it, gather all necessary tools and ensure the electrical system is properly configured for integration.
Step-by-Step Installation Guide
- Turn Off Power: Ensure the main power supply is completely turned off to avoid electric shock.
- Mounting: Secure the circuit breaker in its designated position within the electrical panel.
- Wiring: Connect the incoming and outgoing wires to the appropriate terminals on the circuit breaker.
- Testing: Conduct tests to ensure the circuit breaker is functioning correctly after installation.
Safety Precautions
Always follow safety guidelines when working with electrical systems. Use appropriate protective gear and verify all connections before restoring power.
Maintenance Tips
Routine Checks
Regularly inspect it for signs of wear or damage. Routine checks can help identify potential issues before they escalate.
Troubleshooting Common Issues
If the circuit breaker fails to operate or shows signs of malfunction, refer to the user manual for troubleshooting tips or consult a professional electrician.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS100...250 |
| Product name | EasyPact CVS |
| Device short name | CVS100N |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| poles description | 3P |
| Protected poles description | 3D |
| Earth leakage protection (Vigi add on) | Without |
| [In] rated current | 63 A at 40 °C |
| Network type | AC |
| Utilisation category | Category A |
| [Icu] Breaking capacity | 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 80 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 63 A at 40 °C |
| Protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
|---|---|
| Network frequency | 50/60 Hz |
| Breaking capacity code | N |
| [Ics] rated service breaking capacity | 30 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 50 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 80 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 30000 cycles |
| Electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 |
| Control type | Toggle |
| Thermal protection adjustment range | 0…63 A |
| Long time pick-up adjustment type Ir | Adjustable |
| Long time pick-up adjustment range | 0.7...1 x In |
| Long time delay adjustment type | Fixed |
| Short-time delay adjustment type | Fixed |
| Instantaneous pick-up adjustment type Ii | Fixed |
| instantaneous pick-up adjustment range | 500 A |
| Contact position indicator | Yes |
| Mounting support | Backplate |
| Mounting mode | Fixed |
| Upside connection | Front |
| downside connection | Front |
| Connections - terminals | Screw connection |
| Connection pitch | 35 mm |
| Compatibility code | CVS100 |
| Width | 105 mm |
| Depth | 86 mm |
| Height | 161 mm |
| Net weight | 1.5 kg |
| Standards | EN 60947-2 IEC 60947-2 |
|---|---|
| Product certifications | GOST IEC |
| Electrical shock protection class | Class II |
| IP degree of protection | IP40 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 12 cm |
| Package 1 Width | 13.4 cm |
| Package 1 Length | 18.9 cm |
| Package 1 Weight | 1.77 kg |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 12.39 kg |
