Schneider NU320654CN | Push-button, New Unica, + NO push-button, 10A, 2 modules, screwless terminals, painted, IP4X, anthracite
-
Schneider Electric NU320654CN
-
New Unica push-button 10A
-
2-module push-button anthracite
-
LED indicator push-button Schneider
-
Modular wiring mechanism New Unica
Original price was: EGP 5,514.00.EGP 4,524.00Current price is: EGP 4,524.00.
Description
Schneider NU320654CN | Push-button, New Unica, + NO push-button, 10A, 2 modules, screwless terminals, painted, IP4X, anthracite
Schneider Electric NU320654CN – New Unica 2-Module Push-Button with LED Indicator, Anthracite
Functionality & Compatibility: A 1/0 So (bell symbol) push-button with LED localisation indicator, rated at 10 A and suitable for 250 V AC. Designed as a 2-module mechanism compatible with the New Unica modular system.
Installation & Wiring: Features screwless (spring-clamp) terminals for fast, secure installation. Clip-in mounting mode simplifies assembly
Finish & Design: Anthracite finish (RAL 7021) to blend elegantly with modern décor and installations
Robust Construction: Constructed with halogen-free materials (CuZn37, PBT GF30, PC GF10 FR, ABS-UV stabilised). Dimensions ~45 mm width × 45 mm height × 34.25 mm depth; embedding depth ~21.15 mm; weight ~0.0252 kg.
Explore the Schneider Electric NU320654CN from the New Unica range – 2-module, 10 A push-button with LED indicator, screwless terminals, anthracite finish for modern installs.
Easy to identify release buttons with enhanced ergonomics
Screwless terminals for simple & fast installation
Combine your push button with a fixing frame and matching cover frame
Simple & quick installation
Part of a modular range with a universal format to suit most installation types
Schneider Electric New Unica push-button switch NU320654CN is a mechanism in color anthracite Its connection terminals are screwless terminals.
Being made of Cu. Zn37, PBT (polybutylene terephthalate) GF30, PC (polycarbonate) GF10 FR, thermoplastic ABS-UV stabilised material, this push-button switch is quite reliable and resistant.
It is 45 mm in width, 45 mm in height, 34.25 mm in depth, with an embedding depth of 21.15 mm, And the product weighs 0.0252 kg.
Besides it is halogen free halogen free, which is good for your health.
It is with pilot light LED.
The fixing mode of this device is clip-in. This product is sold in 10.
What’s more, it well satisfied the standard of IEC 60669-1, LV directive, Ro. HS compliant.
It obtained AENOR, CE, EAC, NF certificate as well. Also, it is environment-friendly, with UV resistant, acetone, alcohol, ammonia, bleach, liquid soap, oil, petrol, window-cleaning fluid reached.
The dielectric strength of this push-button switch is 2000 V. And its rated current is 10A. This push-button switch is SVHC (substances of very high concern) free too. Its surface finish is painted powder coated.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range of product | New Unica |
|---|---|
| Product or component type | Push-button |
| Device presentation | Mechanism |
| Technology type | Electromechanical |
| Switch function | + NO push-button |
| Number of rocker | 1 |
| Device application | Bell switch |
| Colour tint | Anthracite (RAL 7021) |
| Type of packing | Flow-pack |
| Rated current | 10 A |
|---|---|
| [Ue] rated operational voltage | 250 V |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Electrical durability | 20000 cycles, cos phi = 0.6 |
| Insulation resistance | > 5 MOhm at 500 V |
| Dielectric strength | 2000 V |
| Minimum load breaking capacity | 200 operations 1.25 In and 1.1 Un, cos phi = 0.3 |
| Opening distance | > 3 mm |
| Actuator | Rocker |
| Number of modules | 2 modules |
| Pilot light | LED, colour: white, current consumption: 0.05 mA |
| Connections - terminals | Screwless terminals |
| Cable cross section | 0…2.5 mm² rigid cable 0…2.5 mm² flexible cable |
| Material | Thermoplastic ABS-UV stabilised: mechanism rocker PC (polycarbonate) GF10 FR: casing CuZn37: terminals PBT (polybutylene terephthalate) GF30: release button |
| Marking | Bell symbol |
| Surface finish | Glossy |
| specific treatment - integrated within the material | Painted |
| fixing mode | Clip-in |
| Width | 45 mm |
| Height | 45 mm |
| Depth | 34.25 mm |
| Embedding depth | 21.15 mm |
| Net weight | 0.0252 kg |
| Ambient air temperature for operation | -5…40 °C |
| Ambient air temperature for storage | -5…50 °C |
| Standards | IEC 60669-1 LV directive |
| Product certifications | CE AENOR EAC NF VDE |
| resistance to chemical agents | Resistant to alcohol (70 %) Resistant to alcohol (96 %) Resistant to A-Lactic Acid Resistant to diluted quaternary ammonium Resistant to diluted bleach Resistant to diluted ammonia Resistant to soapy water Resistant to crystal cleaner Resistant to hydrogen peroxide 10 volumes Resistant to hexane |
| IP degree of protection | IP4X |
|---|---|
| IK degree of protection | IK04 |
| Environmental characteristic | Oil UV resistant Acetone Liquid soap Window-cleaning fluid Petrol Alcohol Bleach |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.5 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 4.5 cm |
| Package 1 Weight | 26.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 8.2 cm |
| Package 2 Width | 17.7 cm |
| Package 2 Length | 18.5 cm |
| Package 2 Weight | 334.0 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 20 |
| Package 3 Height | 15.0 cm |
| Package 3 Width | 30.0 cm |
| Package 3 Length | 40.0 cm |
| Package 3 Weight | 987.0 g |
