Schneider PKF16M435 | PratiKa wander socket – straight – 16 A – 3P + N + E – 380…415 V AC – IP44
Schneider PKF16M435 | PratiKa wander socket – straight – 16 A – 3P + N + E – 380…415 V AC – IP44
EGP 63,612.00
Description
Schneider PKF16M435 | PratiKa wander socket – straight – 16 A – 3P + N + E – 380…415 V AC – IP44
Technical Specifications
- Brand: Schneider Electric
- Model: PKF16M435
- Type: Wander socket (Straight)
- Current Rating: 16A
- Poles: 3P + N + E (Three-phase + Neutral + Earth)
- Voltage Range: 380 to 415V AC
- Frequency: 50/60Hz
- Protection Rating: IP44 (Resistant to water splashes and dust)
- Socket Orientation: Straight
- Material: High-quality insulating materials, impact and corrosion resistant
Key Features
- Robust and Practical Design
- Built with durable materials that resist environmental factors such as moisture and dust, making it ideal for industrial use.
- High Safety Standards
- Secure locking mechanism ensures a firm electrical connection, preventing accidental disconnection or exposure.
- User-Friendly Operation
- Easy to connect and disconnect, simplifying maintenance and installation processes.
- Compliance with International Standards
- Manufactured in accordance with IEC 60309, guaranteeing optimal performance and safety.
- IP44 Protection
- Offers protection against solid objects and water splashes from any direction, making it suitable for both indoor and outdoor use.
- Handles High Electrical Loads Efficiently
- Designed for industrial-grade applications, ensuring stable power supply without energy loss.
Applications
- Workshops and Factories: Ideal for connecting and powering industrial machinery and equipment.
- Construction Sites: Suitable for providing power to tools and equipment in demanding construction environments.
- Warehouses and Storage Facilities: Ensures a safe and reliable power source in logistical operations.
- Outdoor Events: Perfect for exhibitions, festivals, and temporary installations requiring secure power connections.
- Marine and Port Applications: Used in ships and docks where resistance to moisture and salts is essential.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | Mureva |
|---|---|
| Product or component type | Wander socket |
| Device short name | Mureva socket |
| Plug, socket category | Low voltage |
| poles description | 3P + N + E |
| Network type | AC |
| Outlet standard | Industrial |
| Plug, socket, control station shape | Straight |
|---|---|
| [In] rated current | 16 A |
| [Ue] rated operational voltage | 380...415 V |
| Network frequency | 50/60 Hz |
| ground lug clockwise position | 6 h |
| Plug, socket material | Housing: self-extinguishing engineering polymer |
| Contacts material | Sleeves: brass |
| Connections - terminals | Captive screws |
| Cable cross section | 1…4 mm² |
| Cable outer diameter | 8…15 mm |
| Cable entry | Fair lead Cable gland |
| Thread type | Pg 21 |
| Net weight | 0.21 kg |
| Height | 97 mm |
| Width | 97 mm |
| Depth | 153 mm |
| Colour | Grey (RAL 7035) |
| Voltage colour | Red |
| Standards | IEC 60309-1 IEC 60309-2 |
|---|---|
| IP degree of protection | IP44 conforming to IEC 60529 |
| IK degree of protection | IK08 conforming to EN 62262 |
| Fire resistance | 850 °C conforming to IEC 60695-2-1 |
| Relative humidity | 50 % at 40 °C 70 % at 30 °C 90 % at 20 °C |
| Ambient air temperature for operation | 35 °C ( 86400 s ) -25…40 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.500 cm |
| Package 1 Width | 9.500 cm |
| Package 1 Length | 16.500 cm |
| Package 1 Weight | 205.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 17.000 cm |
| Package 2 Width | 27.000 cm |
| Package 2 Length | 27.000 cm |
| Package 2 Weight | 2.206 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 20 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 4.800 kg |
| Warranty | 18 months |
|---|
