Schneider R9F32220 | Miniature circuit breaker (MCB), Resi9, 2P, 20A, C curve, 4500A (IEC/EN 60898-1)
Schneider R9F32220 | Miniature circuit breaker (MCB), Resi9, 2P, 20A, C curve, 4500A (IEC/EN 60898-1)
Original price was: EGP 109,987.00.EGP 67,092.00Current price is: EGP 67,092.00.
Description
Schneider R9F32220: A Comprehensive Guide
Introduction
When it comes to electrical components, reliability and efficiency are paramount. Schneider Electric, a global leader in energy management and automation, offers a range of products designed to meet these demands. One such product is the Schneider R9F32220. In this article, we will explore everything you need to know about this remarkable component, from its basic features to its applications and benefits.
Understanding the Basics
What is Schneider R9F32220?
it is a type of circuit breaker designed to provide reliable protection against electrical overloads and short circuits. It’s a critical component in ensuring the safety and efficiency of electrical systems in various settings, including residential, commercial, and industrial environments.
Key Features and Specifications
- High Interrupting Capacity: It can handle substantial electrical loads without failure.
- Thermal-Magnetic Operation: Combines both thermal and magnetic trip mechanisms for enhanced protection.
- Compact Design: Saves space while providing robust protection.
- Ease of Installation: Designed for straightforward installation and maintenance.
Design and Build
Physical Design
it is designed with both functionality and aesthetics in mind. It features a sleek, compact design that allows it to fit into tight spaces without compromising performance.
Materials Used in Construction
The circuit breaker is constructed from high-quality, durable materials that ensure long-term reliability and performance. The use of fire-resistant plastic and robust metal components enhances its safety and durability.
Durability and Lifespan
Built to last, the Schneider R9F32220 has a long lifespan, even under demanding conditions. Its durability is one of the reasons why it’s a preferred choice among professionals in the electrical industry.
Technical Specifications
Voltage and Current Ratings
The Schneider R9F32220 is rated for a maximum voltage of 240V and can handle a current of up to 20A. This makes it suitable for a wide range of applications, from residential to industrial settings.
Temperature Ratings
This circuit breaker operates efficiently within a temperature range of -25°C to +70°C, ensuring reliable performance in various environmental conditions.
Dimensions and Weight
With a compact design, the Schneider R9F32220 measures approximately 90mm in height, 75mm in width, and 70mm in depth, and weighs around 500 grams. This makes it easy to handle and install.
Installation Process
Pre-installation Requirements
Before installing the Schneider R9F32220, ensure that the electrical panel is de-energized to avoid any risk of electric shock. Gather all necessary tools and verify that the breaker is suitable for the intended application.
Step-by-Step Installation Guide
- Turn Off the Main Power: Ensure the main power supply is turned off.
- Remove the Panel Cover: Access the breaker panel by removing its cover.
- Install the Breaker: Place the Schneider R9F32220 in the designated slot and secure it.
- Connect the Wires: Attach the wires to the breaker terminals, ensuring a secure connection.
- Replace the Panel Cover: Once everything is connected, replace the panel cover.
- Turn On the Main Power: Restore power and test the breaker to ensure proper operation.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | Resi9 |
|---|---|
| product or component type | Miniature circuit-breaker |
| Device application | Distribution |
| poles description | 2P |
| Number of protected poles | 2 |
| [In] rated current | 20 A |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 4500 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Standards | EN/IEC 60898-1 |
| Quality labels | IMQ |
| Network frequency | 50/60 Hz |
|---|---|
| [Ue] rated operational voltage | 400 V AC 50/60 Hz |
| Magnetic tripping limit | 5...10 x In AC |
| Limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 440 V AC |
| [Uimp] rated impulse withstand voltage | 4 kV |
| Control type | Toggle |
| local signalling | ON/OFF indication |
| mounting mode | Clip-on |
| mounting support | DIN rail |
| 9 mm pitches | 4 |
| Height | 81 mm |
| Width | 36 mm |
| Depth | 72 mm |
| Embedding depth | 44 mm |
| net weight | 240 g |
| Colour | White (RAL 9003) |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Connections - terminals | Tunnel type terminals (top or bottom) - 1...25 mm² - rigid Tunnel type terminals (top or bottom) - 1...16 mm² - flexible with ferrule Tunnel type terminals (top or bottom) - 1...16 mm² - flexible |
| Wire stripping length | 14 mm |
| Tightening torque | 2 N.m |
| Earth-leakage protection | Without |
| IP degree of protection | IP20 |
|---|---|
| Pollution degree | 2 conforming to EN/IEC 60898-1 |
| Overvoltage category | III |
| Tropicalisation | 2 conforming to IEC 60068-1 |
| Relative humidity | 95 % at 55 °C |
| Ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…60 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7.500 cm |
| Package 1 Width | 3.600 cm |
| Package 1 Length | 8.500 cm |
| Package 1 Weight | 188.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 22.000 cm |
| Package 2 Width | 8.800 cm |
| Package 2 Length | 8.200 cm |
| Package 2 Weight | 1.169 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 72 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 14.546 kg |
