Schneider R9R51425 | Residual current circuit breaker (RCCB), Resi9, 4P, 25A, AC type, 30mA

Schneider R9R51425 Description

This is a Resi9 RCCB residual current circuit breaker (RCCB).

It is a 4P circuit breaker with In rated current of 25A, AC type protection class and a 30mA earth leakage sensitivity.

This product protects against electrical shock by direct or indirect contact and fire hazards.

As an high sensitivity residual current circuit breaker, it is recommended for all power sockets.

It is also compulsory for all equipment in bathrooms, outdoors. The Resi9 is targeted to the residential market for individual and collective buildings.

This product is compliant with EN/IEC 61008-2-1 standard.

The (Inc/IΔc) conditional rated short circuit current is 6000 A.

The (Im/IΔm) rated making and breaking capacity is 500A.

The electrical endurance is up to 10000 cycles.

The mechanical endurance is up to 20000 cycles.

The Ue operational voltage is 400VAC. It is DIN rail mountable.

The width in 9mm pitches is 8.

The product colour is white (RAL9003). The dimensions are (W) 72mm x (H) 82mm x (D) 73mm.

It has an IP20 degree of protection.

It becomes IP40 once in modular enclosure according to IEC/EN 60529 standard.

operating temperature is from -5°C to 40°C.

The storage temperature is from -40°C to 80°C.

The Schneider R9R51425 is another model number that corresponds to a circuit breaker in Schneider Electric’s product range.

Here’s a description based on typical features and specifications:

• Model Number: R9R51425
• Type: Circuit Breaker
• Application: Used in residential, commercial, and industrial electrical distribution systems for protection against overloads and short circuits.
• Specifications:
  • Rated current: 25 amps
  • Number of poles: 1
  • Rated voltage: Typically 230/400V AC
  • Tripping characteristics: Type C (suitable for general applications with moderate inrush currents)
  • Mounting: DIN rail mountable
  • Breaking capacity: Designed to safely interrupt fault currents up to a specified level, protecting downstream devices and systems.
  • Standards: Complies with international standards for circuit protection and safety.

This description outlines the general features and specifications typical of Schneider Electric’s circuit breakers with the R9R51425 model number. For precise technical details or specific applications, consulting Schneider Electric’s product documentation or contacting their support would provide the most accurate information.
