Schneider XB4BK133B5 Harmony | Illuminated selector switch, metal, green, Ø22, 3 positions, stay put, 24 V AC/DC, 1 NO + 1 NC
Schneider XB4BK133B5 Harmony
EGP 2,529.00
Description
Introduction to Schneider XB4BK133B5 Harmony
it is a versatile push-button control component designed for various industrial and commercial applications. In this comprehensive guide, we’ll explore its features, applications, installation process, maintenance tips, and more to help you understand its functionality and benefits.
Key Features of Schneider XB4BK133B5 Harmony
it boasts several key features that set it apart:
- Durable Construction: Built to withstand harsh industrial environments, ensuring long-term reliability.
- User-Friendly Design: Easy to install and operate, making it accessible for professionals and beginners alike.
- High Compatibility: Seamlessly integrates with other Schneider components, offering versatility in system design.
- Safety Compliance: Meets international safety standards, providing peace of mind in various applications.
Applications of Schneider XB4BK133B5 Harmony
it finds extensive use across different industries:
- Industrial Use: Commonly deployed in control panels, machinery, and automation systems for reliable performance in rugged environments.
- Commercial Use: Ideal for building management systems, HVAC controls, and security systems due to its ease of use and durability.
Installation Guide for Schneider XB4BK133B5 Harmony
Proper installation is essential for optimal performance:
- Prepare the Site: Ensure the installation site is clean and free from obstructions.
- Mounting: Securely mount the Schneider XB4BK133B5 Harmony in the desired location using appropriate hardware.
- Wiring Connection: Follow the provided wiring diagram to connect the switch correctly, ensuring proper functionality.
- Testing: Thoroughly test the installed unit to verify its operation and functionality.
Maintenance Tips for Schneider XB4BK133B5 Harmony
Regular maintenance helps prolong the lifespan of it:
- Scheduled Inspections: Periodically inspect the switch for any signs of wear, damage, or corrosion.
- Prompt Repairs: Address any issues promptly to prevent further damage and ensure uninterrupted operation.
- Environmental Protection: Shield the switch from environmental factors such as moisture and dust to maintain performance.
Where to Buy Schneider XB4BK133B5 Harmony
Ensure you purchase genuine Schneider products from authorized sources:
- Authorized Dealers: Purchase from authorized Schneider dealers to guarantee authenticity and product support.
- Online Retailers: Reputable online platforms like Amazon offer it, but ensure the seller is verified to avoid counterfeit products.
Conclusion
it is a reliable and versatile push-button control component suitable for various industrial and commercial applications. Its robust construction, user-friendly design, and compatibility make it a preferred choice among professionals. By following proper installation and maintenance procedures, you can maximize its performance and longevity in your systems.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range of product | Harmony XB4 |
|---|---|
| Product or component type | Illuminated selector switch |
| Device short name | XB4 |
| Bezel material | Chromium plated metal |
| Fixing collar material | Zamak |
| Head type | Standard |
| Mounting diameter | 22.5 mm |
| Sale per indivisible quantity | 1 |
| Shape of signaling unit head | Round |
| Type of operator | stay put |
| Operator profile | Green standard handle |
| Operator position information | 3 positions +/- 45° |
| Contacts type and composition | 1 NO + 1 NC |
| Contact operation | Slow-break |
| Connections - terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to IEC 60947-1 |
| Light source | Universal LED |
| Bulb base | Integral LED |
| [Us] rated supply voltage | 24 V AC/DC at 50/60 Hz |
| Resistance to high pressure washer | 7000000 Pa at 55 °C, distance : 0.1 m |
|---|---|
| Contacts usage | Standard contacts |
| Positive opening | With conforming to IEC 60947-5-1 appendix K |
| Operating torque | 0.14 N.m NO changing electrical state |
| Mechanical durability | 500000 cycles |
| Tightening torque | 0.8…1.2 N.m conforming to IEC 60947-1 |
| Shape of screw head | Cross compatible with Philips no 1 screwdriver Cross compatible with pozidriv No 1 screwdriver Slotted compatible with flat Ø 4 mm screwdriver Slotted compatible with flat Ø 5.5 mm screwdriver |
| Contacts material | Silver alloy (Ag/Ni) |
| Short-circuit protection | 10 A cartridge fuse type gG conforming to IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A conforming to IEC 60947-5-1 |
| [Ui] rated insulation voltage | 600 V (pollution degree 3) conforming to IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
| [Ie] rated operational current | 3 A at 240 V, AC-15, A600 conforming to IEC 60947-5-1 6 A at 120 V, AC-15, A600 conforming to IEC 60947-5-1 0.1 A at 600 V, DC-13, Q600 conforming to IEC 60947-5-1 0.27 A at 250 V, DC-13, Q600 conforming to IEC 60947-5-1 0.55 A at 125 V, DC-13, Q600 conforming to IEC 60947-5-1 1.2 A at 600 V, AC-15, A600 conforming to IEC 60947-5-1 |
| Electrical durability | 1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN 60947-5-1 appendix C 1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN 60947-5-1 appendix C 1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN 60947-5-1 appendix C 1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN 60947-5-1 appendix C 1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN 60947-5-1 appendix C |
| Electrical reliability | Λ < 10exp(-6) at 5 V and 1 mA in clean environment conforming to IEC 60947-5-4 Λ < 10exp(-8) at 17 V and 5 mA in clean environment conforming to IEC 60947-5-4 |
| Signalling type | Steady |
| Supply voltage limits | 19.2…30 V DC 21.6…26.4 V AC |
| Current consumption | 18 mA |
| Service life | 100000 h at rated voltage and 25 °C |
| Surge withstand | 1 kV conforming to IEC 61000-4-5 |
| Device presentation | Complete product |
| Protective treatment | TH |
|---|---|
| Ambient air temperature for storage | -40…70 °C |
| Ambient air temperature for operation | -40…70 °C |
| Electrical shock protection class | Class I conforming to IEC 60536 |
| IP degree of protection | IP66 conforming to IEC 60529 IP67 IP69 IP69K |
| NEMA degree of protection | NEMA 13 NEMA 4X |
| IK degree of protection | IK04 conforming to IEC 50102 |
| Standards | UL 508 IEC 60947-5-4 JIS C8201-5-1 IEC 60947-5-5 IEC 60947-5-1 CSA C22.2 No 14 IEC 60947-1 JIS C8201-1 |
| Product certifications | BV UL CSA DNV LROS (Lloyds register of shipping) |
| Vibration resistance | 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Resistance to fast transients | 2 kV conforming to IEC 61000-4-4 |
| Resistance to electromagnetic fields | 10 V/m conforming to IEC 61000-4-3 |
| Resistance to electrostatic discharge | 6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2 |
| Electromagnetic emission | Class B conforming to IEC 55011 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.700 cm |
| Package 1 Width | 3.400 cm |
| Package 1 Length | 5.300 cm |
| Package 1 Weight | 109.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 8.700 cm |
| Package 2 Width | 3.400 cm |
| Package 2 Length | 26.800 cm |
| Package 2 Weight | 549.000 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 50 |
| Package 3 Height | 15.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 5.835 kg |
| Warranty | 18 months |
|---|
