Telemecanique Sensors XCRF17 | Limit switch, Limit switches XC Standard, XCR, metal stay put T rods lever square rod 6 mm, 2X(1NC+NO)
Telemecanique Sensors XCRF17 | Limit switch, Limit switches XC Standard, XCR, metal stay put T rods lever square rod 6 mm, 2X(1NC+NO)
Original price was: EGP 23,569,728.00.EGP 1,107,777.00Current price is: EGP 1,107,777.00.
Description
Telemecanique Sensors XCRF17 | Limit switch, Limit switches XC Standard, XCR, metal stay put T rods lever square rod 6 mm, 2X(1NC+NO)
Product Overview: Telemecanique Sensors XCRF17 Limit Switch
The Telemecanique XCRF17 is a robust limit switch from the XC Standard (XCR) series. It is designed for industrial applications where reliable position detection is essential. This model features a metal stay-put T-rod lever with a square 6 mm rod and includes two contact blocks, each providing 1 normally open (NO) and 1 normally closed (NC) contact.
Key Features
-
Product Type: Limit switch
-
Series: XC Standard
-
Model: XCRF17
-
Actuator Type: Metal stay-put T-rod lever
-
Rod Shape: Square rod, 6 mm
-
Contact Configuration: 2 x (1NC + 1NO)
-
Operating Mechanism: Snap action
-
Enclosure: Durable metal housing
-
Mounting: Surface mount, adjustable
Functional Description
-
Detects mechanical movement or position of machine components
-
The T-rod lever remains in position when moved (stay-put mechanism)
-
Designed for harsh industrial environments with a high level of durability
-
Suitable for applications requiring two separate contact outputs
Applications
-
Position sensing in industrial machinery
-
Conveyor belt systems
-
Packaging equipment
-
Safety interlocks and end-of-travel detection
-
Lifting and hoisting equipment
-
Automated manufacturing lines
Benefits
-
Durable metal construction for long-term reliability
-
Dual contact blocks offer flexible control options
-
Stay-put lever design ensures precise actuation
-
Easy integration into standard mounting setups
-
Designed to perform in demanding industrial environments
Additional information
| brands | Telemecanique Sensors |
|---|
Specifications
Main
Range of product
OsiSense XC
Series name
special format
Product or component type
limit switch
Product specific application
for hoisting and mechanical handling applications
Device short name
XCR
Sensor design
-
Body type
fixed
Head type
rotary head
Material
metal
Fixing mode
by the body
Movement of operating head
rotary
Type of operator
Stay put crossed rods lever metal square rod 6 mm
Type of approach
Lateral approach, 2 directions
Body material
zinc alloy
Electrical connection
Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm²
Contacts type and composition
2 x (1 NC + 1 NO)
Cable entry
1 entry tapped for Pg 13.5 cable gland, cable outer diameter: 9-12 mm conforming to NF C 68-300
Contact operation
snap action
Switch actuation
by any moving part
Positive opening
with
Complementary
Contact block per direction [control circuit]
1 per direction
Contacts insulation form
Zb
Contact code designation
A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to IEC 60947-5-1 appendix A, Q300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to IEC 60947-5-1 appendix A
Resistance across terminals
25 MOhm conforming to IEC 60255-7 category 3
Terminals description ISO n°1
(21-22)NC
(13-14)NO
Environment
Shock resistance
68 gn conforming to IEC 60068-2-27
Vibration resistance
9 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
IP degree of protection
IP54 conforming to IEC 60529
Overvoltage category
Class I conforming to IEC 61140, class I conforming to NF C 20-030
Protective treatment
TC
Product certifications
CSA
CCC
Standards
CSA C22.2 No 14
NF C 79-130
IEC 60947-5-1
IEC 60204-1
Packing Units
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
9 CENTIMETER
Package 1 width
31.7 CENTIMETER
Package 1 length
12.4 CENTIMETER
Package 1 weight
1.121 KILOGRAM
Unit type of package 2
S02
Number of units in package 2
3
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
3.914 KILOGRAM
Unit type of package 3
P06
Number of units in package 3
48
Package 3 height
75 CENTIMETER
Package 3 width
60 CENTIMETER
Package 3 length
80 CENTIMETER
Package 3 weight
69.588 KILOGRAM
