Schneider 28908 | switch-disconnector Compact INS100 – 3 poles – 100 A
Schneider 28908 | switch-disconnector Compact INS100 – 3 poles – 100 A
Original price was: EGP 634,558.00.EGP 406,117.00Current price is: EGP 406,117.00.
Description
Schneider 28908 | switch-disconnector Compact INS100 – 3 poles – 100 A
1. Technical Specifications
- Model: 28908 Compact INS100
- Type: Switch-Disconnector
- Number of Poles: 3P (Three Poles)
- Rated Current: 100A
- Operating Voltage: Up to 690V AC
- Frequency: 50/60Hz
- Breaking Capacity: Does not provide short-circuit protection (requires external fuses)
- Mounting Options: DIN rail or panel mounting
- Mechanical Durability: Designed for frequent switching operations
- Operating Mechanism: Manual rotary handle
- Compliance Standards: IEC 60947-3
2. Key Features
A. Safe and Reliable Electrical Isolation
- Ensures complete disconnection of circuits, allowing safe maintenance and preventing electrical hazards.
B. High Mechanical Durability
- Built to withstand frequent switching operations, making it ideal for industrial applications.
C. Three-Pole Configuration for Balanced Power Distribution
- Ensures efficient phase isolation in three-phase electrical systems.
D. Easy and Flexible Installation
- Can be mounted on a DIN rail or directly on a panel, providing adaptability for different electrical setups.
E. User-Friendly and Safe Operation
- Equipped with a manual rotary handle with clear ON/OFF positions, ensuring ease of use and operational safety.
3. Applications and Uses
The Schneider 28908 Compact INS100 is widely used in industrial, commercial, and utility applications, including:
A. Electrical Distribution Systems
- Used in main and sub-distribution panels to isolate power safely.
B. Industrial Machinery and Equipment
- Provides a manual disconnection option for electrical maintenance of heavy machinery.
C. Renewable Energy Installations
- Used in solar and wind power systems for isolating circuits when needed.
D. Commercial Buildings and Infrastructure
- Ensures safe and controlled power distribution in offices, hospitals, data centers, and large facilities.
-
4. Key Benefits of Schneider 28908 Compact INS100
Ensures safe circuit isolation for maintenance
Durable design for long-term reliability
Three-pole configuration for balanced power distribution
Easy installation on DIN rail or panel
Manual rotary handle for simple and safe operation
Compliant with global electrical safety standards
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | ComPact |
|---|---|
| product name | ComPacT INS |
| Product or component type | Switch disconnector |
| Poles description | 3P |
| network type | AC DC |
| Network frequency | 50/60 Hz |
| [Ie] rated operational current | AC-22A: 100 A AC 50/60 Hz 220/240 V AC-22A: 100 A AC 50/60 Hz 380/415 V AC-22A: 100 A AC 50/60 Hz 440/480 V AC-22A: 100 A AC 50/60 Hz 500 V AC-22A: 100 A AC 50/60 Hz 660/690 V AC-23A: 100 A AC 50/60 Hz 220/240 V AC-23A: 100 A AC 50/60 Hz 380/415 V AC-23A: 100 A AC 50/60 Hz 440/480 V AC-23A: 100 A AC 50/60 Hz 500 V AC-23A: 63 A AC 50/60 Hz 660/690 V DC-22A: 100 A DC 125 V 2 poles in series DC-23A: 100 A DC 125 V 2 poles in series |
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ith] conventional free air thermal current | 100 A at 60 °C |
| [Icm] rated short-circuit making capacity | 154 kA with upstream protection circuit breaker 690 V AC at 50/60 Hz 20 kA switch-disconnector alone 690 V AC at 50/60 Hz |
| [Ue] rated operational voltage | 125 V DC 690 V AC 50/60 Hz |
| Suitability for isolation | Yes |
| Contact position indicator | Yes |
| Visible break | No |
| Pollution degree | 3 |
| Control type | Rotary handle |
|---|---|
| Handle colour | Black |
| Mounting mode | Fixed |
| Mounting support | Plate DIN rail |
| Upside connection | Front |
| Downside connection | Front |
| Maximum power | AC-23: 22 kW at 220/240 V AC 50/60 Hz AC-23: 45 kW at 380/415 V AC 50/60 Hz AC-23: 55 kW at 440 V AC 50/60 Hz AC-23: 55 kW at 500/525 V AC 50/60 Hz AC-23: 55 kW at 660/690 V AC 50/60 Hz |
| Rated duty | Uninterrupted |
| Intermittent duty class | Class 120 - 60 % |
| [Icw] rated short-time withstand current | 1 kA during 30 s conforming to IEC 60947-3 1.23 kA during 20 s conforming to IEC 60947-3 3.175 kA during 3 s conforming to IEC 60947-3 5.5 kA during 1 s conforming to IEC 60947-3 |
| Mechanical durability | 15000 cycles |
| Electrical durability | AC-22A: 1500 cycles 220/240 V AC 50/60 Hz AC-22A: 1500 cycles 380/415 V AC 50/60 Hz AC-22A: 1500 cycles 440 V AC 50/60 Hz AC-22A: 1500 cycles 500 V AC 50/60 Hz AC-23A: 1500 cycles 220/240 V AC 50/60 Hz AC-23A: 1500 cycles 380/415 V AC 50/60 Hz AC-23A: 1500 cycles 440 V AC 50/60 Hz AC-23A: 1500 cycles 500 V AC 50/60 Hz DC-22A: 1500 cycles 250 V DC 2 poles in series DC-23A: 1500 cycles 250 V DC 2 poles in series AC-22A: 1500 cycles 690 V AC 50/60 Hz AC-23A: 1500 cycles 690 V AC 50/60 Hz |
| Connection pitch | 30 mm |
| Height | 100 mm |
| Width | 135 mm |
| Depth | 62.5 mm |
| Product weight | 0.8 kg |
| Standards | IEC 60947-3 IEC 60947-1 |
|---|---|
| Product certifications | CCC KEMA-KEUR |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to EN 50102 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 13.400 cm |
| Package 1 Width | 11.500 cm |
| Package 1 Length | 15.400 cm |
| Package 1 Weight | 1.024 kg |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 10.572 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 80 |
| Package 3 Height | 44.000 cm |
| Package 3 Width | 80.000 cm |
| Package 3 Length | 120.000 cm |
| Package 3 Weight | 99.000 kg |
| Warranty | 18 months |
|---|
