Schneider A9N61508 | miniature circuit breaker – C60H – 1 pole – 10 A – C curve

Technical Specifications A9N61508

• Product Reference: A9N61508

• Series: Acti9 C60H

• Device Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 10 A

• Tripping Curve: C Curve (trips between 5–10 × In)

• Breaking Capacity: Up to 6 kA (IEC/EN 60898-1)

• Rated Operational Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Mounting Type: DIN rail (modular)

• Terminal Connection: Screw terminals, top and bottom

• Degree of Protection: IP20 (when installed in enclosure)

• Standards:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

Key Features:

• Reliable 10 A Protection
  Ensures safety and continuity in circuits with low to medium load demands.

• C Curve Tripping
  Provides a balance between sensitivity and tolerance to inrush currents.

• Space-Saving Modular Design
  Optimized for compact control panels and distribution boards.

• High Durability
  Built to withstand frequent operation and harsh environments.

• Quick Installation
  Easy DIN rail mounting with robust screw terminals for secure wiring.

• Global Compliance
  Certified to major international standards for universal application.

Applications:

• Residential Distribution Boards
  Ideal for protecting socket and lighting circuits.

• Commercial Installations
  Suitable for office lighting, signage systems, and auxiliary equipment.

• Control and Automation Panels
  Protects circuits powering controllers, relays, and I/O devices.

• Small Motor Loads
  Supports protection of devices with moderate start-up currents.

• Backup and Emergency Systems
  Reliable operation for low-current standby circuits or critical loads.
