Schneider A9K24150 | Miniature circuit-breaker, Acti9 iK60N, 1P, 50 A, C curve, 6000 A (IEC 60898-1)
Schneider A9K24150 | Miniature circuit-breaker, Acti9 iK60N, 1P, 50 A, C curve, 6000 A (IEC 60898-1)
Original price was: EGP 5,814.00.EGP 4,187.00Current price is: EGP 4,187.00.
Description
Schneider A9K24150: The Ultimate Guide
Introduction
In the world of electrical systems, ensuring safety and reliability is paramount. One crucial component that plays a significant role in this is the circuit breaker. Among the various options available, the Schneider A9K24150 stands out as a top choice for many. But what exactly is it, and why is it so important?
Understanding the Schneider A9K24150
it is a high-performance circuit breaker designed to protect electrical circuits from damage caused by overloads or short circuits. It is part of Schneider Electric’s Acti 9 series, known for its advanced safety features and durability.
Overview and Specifications
it boasts impressive specifications:
- Rated current: 50A
- Breaking capacity: 10kA
- Number of poles: 2
- Voltage: 230/400V
Key Features
- Safety: it includes robust safety features that ensure reliable operation.
- Efficiency: It is designed to be energy-efficient, reducing power consumption.
- Compact Design: Its compact size makes it suitable for various installations without requiring much space.
- Durability: Built to last, the A9K24150 offers long-term reliability.
Applications of Schneider A9K24150
The versatility of it makes it suitable for a wide range of applications.
Residential Use
In homes, it ensures the safety of electrical systems, protecting appliances and preventing electrical fires.
Commercial Use
For businesses, it provides reliable protection for electrical infrastructure, minimizing downtime and maintaining smooth operations.
Industrial Use
In industrial settings, the A9K24150 is crucial for safeguarding heavy machinery and ensuring the stability of power supply systems.
Installation of Schneider A9K24150
Pre-Installation Requirements
Before installing the Schneider A9K24150, ensure you have the necessary tools and a clear understanding of your electrical system.
Step-by-Step Installation Guide
- Turn Off Power: Ensure the power supply is completely shut off to avoid any accidents.
- Mounting: Secure the circuit breaker in the designated slot.
- Wiring: Connect the wires to the appropriate terminals, ensuring a tight and secure connection.
- Testing: Once installed, test the circuit breaker to ensure it functions correctly.
Safety Precautions
Always adhere to safety guidelines to prevent electrical hazards. Wear protective gear and consult a professional if unsure about any step.
Advantages of Using Schneider A9K24150
Durability and Reliability
The A9K24150 is built to withstand harsh conditions, ensuring long-term performance.
Energy Efficiency
Designed to be energy-efficient, it helps reduce overall power consumption, making it an eco-friendly choice.
Cost-Effectiveness
Despite its advanced features, it is reasonably priced, offering great value for money.
Maintenance and Troubleshooting
Regular Maintenance Tips
- Inspection: Regularly inspect the circuit breaker for signs of wear or damage.
- Cleaning: Keep the unit clean and free from dust and debris.
- Testing: Periodically test the breaker to ensure it operates correctly.
Common Issues and Solutions
- Tripping: If the breaker trips frequently, it may be due to an overload or short circuit. Identify and resolve the underlying issue.
- Wear and Tear: Over time, components may wear out. Replace them as needed to maintain performance.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Device application | Distribution |
|---|---|
| Range | Acti9 |
| Product name | Acti9 iK60 |
| product or component type | Miniature circuit-breaker |
| Device short name | iK60N |
| poles description | 1P |
| Number of protected poles | 1 |
| [In] rated current | 50 A at 30 °C |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Suitability for isolation | Yes conforming to EN/IEC 60898-1 |
| Standards | EN/IEC 60898-1 |
| Network frequency | 50/60 Hz |
|---|---|
| Magnetic tripping limit | 5...10 x In |
| [Ics] rated service breaking capacity | 6000 A 100 % conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz |
| Limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 440 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to EN/IEC 60898-1 |
| Contact position indicator | No |
| Control type | Toggle |
| local signalling | ON/OFF indication |
| mounting mode | Clip-on |
| mounting support | DIN rail |
| 9 mm pitches | 2 |
| Height | 85 mm |
| Width | 18 mm |
| Depth | 78.5 mm |
| net weight | 100 g |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Locking options description | Padlocking device |
| Connections - terminals | Tunnel type terminal (top or bottom) 1…35 mm² rigid Tunnel type terminal (top or bottom) 1…25 mm² flexible |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 3.5 N.m top or bottom |
| Earth-leakage protection | Without |
| IP degree of protection | IP20 conforming to IEC 60529 |
|---|---|
| Pollution degree | 2 conforming to EN/IEC 60898-1 |
| Overvoltage category | II |
| Ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.000 cm |
| Package 1 Width | 7.500 cm |
| Package 1 Length | 9.500 cm |
| Package 1 Weight | 124.300 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 8.500 cm |
| Package 2 Width | 10.000 cm |
| Package 2 Length | 22.000 cm |
| Package 2 Weight | 1.550 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 132 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 17.439 kg |
| Warranty | 18 months |
|---|
