Schneider A9N61504 | miniature circuit breaker – C60H – 1 pole – 4 A – C curve

Technical Specifications A9N61504

• Product Reference: A9N61504

• Series: Acti9 C60H

• Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 4 A

• Tripping Curve: C Curve (trips at 5 to 10 times rated current)

• Breaking Capacity: Up to 6 kA (as per IEC/EN 60898-1)

• Rated Operational Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Installation: DIN rail mount

• Terminal Type: Screw terminals (top and bottom)

• Protection Degree: IP20 (when enclosed)

• Compliance:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

Key Features:

• Accurate Low-Current Protection
  Suitable for circuits requiring 4 A protection, such as low-power devices or instrumentation.

• C Curve Tripping
  Allows safe operation on circuits with brief inrush currents like relay coils or lighting transformers.

• Compact Modular Design
  Saves space in panels and simplifies configuration.

• Trusted Schneider Quality
  High durability and performance under normal and fault conditions.

• Easy Mounting
  Snap-on DIN rail installation with secure wiring.

• Versatile Use
  Compatible with other Acti9 components and accessories.

Applications:

• Lighting Control Circuits
  Ideal for managing small lighting loads or LED driver circuits.

• Automation and Control Panels
  Protects low-current control lines or signaling equipment.

• Residential and Office Installations
  Used for dedicated protection of circuits like alarm systems or thermostats.

• Instrumentation
  Suitable for sensitive electronic systems requiring precision protection.

• Public Buildings and Commercial Spaces
  Ensures circuit protection in structured electrical installations.
