Schneider C10B6TM100 | Circuit breaker ComPacT NSX100B, 25kA at 415VAC, TMD trip unit 100A, 4 poles 3d
Schneider C10B6TM100 | Circuit breaker ComPacT NSX100B, 25kA at 415VAC, TMD trip unit 100A, 4 poles 3d
Original price was: EGP 178,524.00.EGP 117,826.00Current price is: EGP 117,826.00.
Description
Key Specifications Schneider C10B6TM100
-
Type: ComPacT NSX100B Circuit Breaker
-
Rated Current: 100A
-
Breaking Capacity: 25 kA at 415V AC
-
Number of Poles: 4 poles (three-phase + neutral)
-
Trip Unit: TMD (Thermal-Magnetic) trip unit for overload and short-circuit protection
-
Voltage Rating: Suitable for use at 415V AC
-
Frame Size: NSX100B, suitable for medium-sized electrical installations
-
Pole Configuration: 4 poles, making it ideal for three-phase systems with neutral (3D)
Features
-
Thermal-Magnetic Trip Unit (TMD): The TMD trip unit offers both thermal protection (for overloads) and magnetic protection (for short circuits). This dual protection ensures that the breaker reacts quickly to electrical faults, safeguarding both the wiring and connected equipment.
-
High Breaking Capacity: With a breaking capacity of 25 kA at 415V AC, the ComPacT NSX100B can interrupt high fault currents, preventing damage to the electrical installation in case of short circuits.
-
Four Poles: This circuit breaker is a 4-pole version, providing protection for three-phase circuits with an additional neutral pole. It’s designed for applications that require protection for both the live and neutral conductors in a balanced manner.
-
Compact and Reliable Design: Schneider Electric’s ComPacT range is known for its compact size, making it easy to install in both new and existing electrical distribution systems. The device is built to withstand harsh conditions and operate reliably over time.
-
Wide Range of Applications: This circuit breaker is versatile and suitable for various industrial, commercial, and residential applications, such as motor protection, lighting, and distribution panels.
Applications
-
Industrial Electrical Distribution: Ideal for protecting electrical circuits in industrial plants, factories, and manufacturing facilities.
-
Motor Protection: The breaker can be used to protect motors and other heavy electrical equipment from overloads and short circuits, ensuring safe operation in motor-driven systems.
-
Commercial Buildings: Used in commercial buildings for power distribution, protecting both lighting and power circuits.
-
Residential Power Panels: The C10B6TM100 can also be used in residential power distribution panels where multi-phase systems are in place.
-
HVAC Systems: It’s suitable for protecting HVAC (Heating, Ventilation, and Air Conditioning) systems, which often require high power and complex wiring systems
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | ComPacT new generation |
|---|---|
| Product name | ComPacT NSX new generation |
| Device short name | NSX100B |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| poles description | 4P |
| Protected poles description | 3D |
| Neutral position | Left |
| [In] rated current | 100 A at 40 °C |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| network type | AC |
| network frequency | 50/60 Hz |
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
| Utilisation category | Category A |
| [Icu] rated ultimate short-circuit breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 15 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 |
| Performance level | B 25 kA 415 V AC |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit protection functions | LI |
| Control type | Toggle |
| Circuit breaker mounting mode | Fixed |
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz |
|---|---|
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ics] rated service short-circuit breaking capacity | 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 7 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 50000 cycles |
| Electrical durability | 50000 cycles at 440 V In/2 30000 cycles at 440 V In 20000 cycles at 690 V In/2 10000 cycles at 690 V In |
| Power dissipation per pole | 8.8 W |
| mounting support | Backplate |
| mounting position | Horizontal and vertical Flat on the back |
| Upside connection | Front |
| downside connection | Front |
| Connection pitch | 35 mm |
| Protection type | L : for overload protection (thermal) I : for short-circuit protection (magnetic) |
| Trip unit rating | 100 A at 40 °C |
| Long-time pick-up adjustment type Ir (thermal protection) | Adjustable |
| [Ir] long-time protection pick-up adjustment range | 0.7...1 x In |
| Long-time protection delay adjustment type tr | Fixed |
| [tr] long-time protection delay adjustment range | 120…400 s at 1.5 x In 15 s at 6 x Ir |
| Neutral protection settings | No protection (3D) |
| Instantaneous protection pick-up adjustment type Ii | Fixed |
| [Ii] instantaneous protection pick-up adjustment range | 800 A |
| Earth-leakage protection | Without |
| Number of slots for electrical auxiliaries | 5 slot(s) |
| Width (W) | 140 mm |
| Height (H) | 161 mm |
| Depth (D) | 86 mm |
| Net weight | 2.4 kg |
| Standards | EN/IEC 60947-2 |
|---|---|
| Overvoltage category | Class II |
| Electrical shock protection class | Class II |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to IEC 62262 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0...2000 m without derating 2000 m...5000 m with derating |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 13.5 cm |
| Package 1 Width | 14.5 cm |
| Package 1 Length | 19 cm |
| Package 1 Weight | 2.307 kg |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 23 cm |
| Package 2 Width | 39 cm |
| Package 2 Length | 49 cm |
| Package 2 Weight | 14.7275 kg |
| Unit Type of Package 3 | PAL |
| Number of Units in Package 3 | 48 |
| Package 3 Height | 107 cm |
| Package 3 Width | 40 cm |
| Package 3 Length | 60 cm |
| Package 3 Weight | 122.82 kg |
