Schneider A9N61502 | miniature circuit breaker – C60H – 1 pole – 2 A – C curve

Technical Specifications A9N61502

• Product Reference: A9N61502

• Series: Acti9 C60H

• Device Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 2 A

• Tripping Curve: C Curve (trips at 5 to 10 × rated current)

• Breaking Capacity:

  • Typically 6 kA (depending on installation and standard applied)

• Rated Operational Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Mounting Type: DIN rail (modular)

• Connection: Screw terminals, top and bottom

• Standards Compliance:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

• Degree of Protection: IP20 (when installed in enclosure)

Key Features:

• Accurate Circuit Protection
  Ideal for small circuits requiring precise protection such as sensors, control loops, or lighting.

• C Curve Trip Characteristic
  Offers reliable protection against overload and short circuits with tolerance for devices with inrush currents.

• High Durability
  Engineered for long-lasting performance in demanding conditions.

• Compact Design
  Saves space in distribution boards and control panels.

• Quick DIN Rail Installation
  Snap-on mounting with secure terminal connections for ease of setup.

• Trusted Brand
  Part of Schneider Electric’s industry-leading Acti9 protection range.

Applications:

• Control Panels
  Used for protecting low-power control circuits and relays.

• Lighting Circuits
  Suitable for both residential and commercial lighting with small loads.

• Security Systems
  Powers and protects sensitive alarm or access control devices.

• Industrial Automation
  Applies to instrumentation circuits, PLC input protection, and sensor feeds.

• Distribution Boards
  An excellent choice for protecting branch circuits in homes or offices.
