Schneider LAEM5 | Mechanical interlock,EasyPact TVS,for LC1E120-E160

Schneider LAEM5 | Mechanical Interlock for EasyPact TVS LC1E120-E160 Contactors

1. Introduction

The Schneider LAEM5 is a mechanical interlock designed for EasyPact TVS contactors, specifically for models LC1E120 to LC1E160. It ensures safe and reliable interlocking between two contactors in reversing motor applications or changeover circuits, preventing simultaneous activation of both contactors.

2. Key Features

• Compatible Contactors: LC1E120, LC1E160

• Prevents Simultaneous Contact Activation

• Mechanical Interlock Without Electrical Wiring

• Ensures Safe Reversing & Changeover Operations

• Durable & Reliable for Industrial Use

• Easy to Install & Maintain

3. Technical Specifications

• Product Series: EasyPact TVS

• Function: Mechanical Interlock

• Compatible With: LC1E120, LC1E160 contactors

• Mounting Type: Direct mounting between two contactors

• Material: High-strength industrial plastic and metal components

• Operating Temperature: -5°C to +55°C

• Compliance Standards: IEC 60947-4-1

4. Applications

The LAEM5 mechanical interlock is commonly used in industrial motor control and power switching applications, including:

• Reversing Motor Starters – Prevents simultaneous forward & reverse operation

• Changeover Circuits – Ensures safe power switching between sources

• Automatic Transfer Switches (ATS) – Supports load transfer in electrical panels

• Heavy Machinery & Conveyor Systems – Provides operational safety

5. Benefits

• Enhances Safety – Prevents electrical faults caused by simultaneous contactor engagement

• Simple & Effective Design – No additional wiring required

• Highly Durable for Industrial Use – Built for heavy-duty applications

• Reduces Maintenance & System Failures – Ensures smooth and reliable contactor operation
