Schneider LRE16 | Thermal Overload Relay

The Schneider LRE16 is a thermal overload relay from the EasyPact TVS series, designed for motor protection against overloads and phase failures. This relay ensures reliable operation and extends the lifespan of electric motors in industrial and commercial applications.

1. General Specifications

• Product Name: Schneider LRE16

• Series: EasyPact TVS

• Type: Thermal Overload Relay

• Current Range: 9A to 13A

• Trip Class: Class 10A

• Mounting: Direct mounting on EasyPact TVS contactors

• Reset Mode: Manual or Automatic

• Phase Failure Protection: Yes

2. Key Features

Reliable Motor Protection – Prevents motor damage due to overloads.
Adjustable Current Range (9A-13A) – Offers flexibility for various motor ratings.
Direct Mounting on Contactors – Compatible with EasyPact TVS contactors for seamless integration.
Automatic & Manual Reset Options – Allows for operational flexibility.
Compact & Robust Design – Suitable for industrial environments.

3. Applications

🔹 Pumps
🔹 Fans & Blowers
🔹 Conveyors
🔹 Machine Tools
🔹 Compressors

4. Protection & Safety Features

Overload Protection – Prevents excessive motor heating.
Phase Failure Detection – Enhances motor reliability.
Trip Indication – Helps in quick troubleshooting.

5. Installation & Maintenance

• Simple & Quick Installation with direct mounting on compatible contactors.

• Low Maintenance due to its durable and high-quality components.

• Easy Current Adjustment via a user-friendly dial.
