Schneider LV432894 | circuit breaker ComPact NSX630N, 50 kA at 415 VAC, MicroLogic 2.3 trip unit 630 A, 4 poles 4d

Technical Specifications:

• Type: Circuit Breaker

• Model: Schneider LV432894 | ComPact NSX630N

• Nominal Current: 630 Amps

• Maximum Breaking Capacity: 50 kA at 415 VAC

• Number of Poles: 4 Poles

• Trip Unit: MicroLogic 2.3 (Electronic Trip Unit)

• Short-Circuit Protection: Capable of withstanding short-circuit currents up to 50 kA at 415 VAC, offering strong protection against large fault currents in industrial and commercial applications.

Features:

1. Advanced MicroLogic Trip Unit:
   The MicroLogic 2.3 electronic trip unit offers sophisticated protection with adjustable settings for overload, short-circuit, and ground fault protection. This flexibility ensures optimal protection tailored to specific operational needs and conditions.

2. High Short-Circuit Withstand Capacity:
   With the ability to withstand 50 kA of short-circuit current at 415 VAC, the ComPact NSX630N is designed for environments where large fault currents may occur, such as in high-power industrial facilities, large commercial buildings, or heavy machinery operations.

3. 4-Pole Configuration:
   The 4-pole design is suitable for three-phase systems with a neutral, providing comprehensive protection for all phases and the neutral conductor. This feature allows the circuit breaker to effectively disconnect the entire electrical system during fault conditions, improving overall safety.

4. Durability and Reliability:
   The ComPact NSX630N circuit breaker is built with durable materials, ensuring reliable long-term performance even under demanding environmental conditions. It is designed to withstand the rigors of industrial and commercial environments.

5. Energy Efficiency:
   By providing precise and reliable protection against overloads and electrical faults, this breaker helps optimize the overall energy efficiency of the system, reducing downtime and preventing energy loss due to electrical issues.

Applications:

• Industrial Facilities:
  The Schneider LV432894 circuit breaker is ideal for protecting large industrial electrical systems, machinery, and motors, providing protection against overloads and short circuits in high-power environments.

• Commercial Infrastructure:
  Suitable for use in large commercial buildings such as office complexes, shopping malls, and hospitals, this breaker ensures the safe and efficient operation of essential electrical systems, including lighting, HVAC, and power distribution networks.

• Motor Control Centers (MCC):
  This breaker is well-suited for motor control applications, ensuring the protection of motor-driven systems like pumps, fans, and compressors, safeguarding them from electrical faults and overloads.

• Power Distribution Networks:
  It can be used in electrical distribution systems to protect circuits and equipment, ensuring reliable operation and preventing the spread of faults within the network.

• Data Centers and Critical Infrastructure:
  In environments that demand continuous power supply, such as data centers, this breaker guarantees the stability and reliability of electrical systems, protecting critical equipment from power disturbances.
