Schneider LV432896 | circuit breaker ComPact NSX630H, 70 kA at 415 VAC, MicroLogic 2.3 trip unit 630 A, 4 poles 4d

Technical Specifications:

• Type: Circuit Breaker

• Model: Schneider LV432896 | ComPact NSX630H

• Nominal Current: 630 Amps

• Maximum Breaking Capacity: 70 kA at 415 VAC

• Number of Poles: 4 Poles

• Trip Unit: MicroLogic 2.3 (Electronic Trip Unit)

• Short-Circuit Protection: Capable of withstanding short-circuit currents up to 70 kA at 415 VAC, offering high-level protection against large fault currents.

Features:

1. Advanced MicroLogic Trip Unit:
   The MicroLogic 2.3 electronic trip unit ensures sophisticated and customizable protection for overloads, short circuits, and ground faults. The adjustable trip settings enable this circuit breaker to be fine-tuned to suit specific operational needs, making it adaptable to various electrical system configurations.

2. High Short-Circuit Withstand Capacity:
   With a 70 kA breaking capacity at 415 VAC, the ComPact NSX630H provides outstanding protection against large fault currents, making it ideal for use in high-power industrial applications, large commercial buildings, and other environments where significant fault currents may occur.

3. 4-Pole Configuration:
   The 4-pole design is suitable for three-phase electrical systems with a neutral conductor, ensuring comprehensive protection for all phases and the neutral line. This setup enables the breaker to disconnect the entire system during faults or overloads, preventing damage to the electrical network.

4. Durability and Longevity:
   Built with high-quality materials and advanced engineering, the ComPact NSX630H circuit breaker is designed for long-lasting performance and reliability. It is constructed to endure the demanding conditions found in industrial and commercial environments.

5. Energy Efficiency:
   By providing reliable protection against overloads and short circuits, this circuit breaker contributes to the overall energy efficiency of the electrical system. It helps to minimize energy loss due to faults and optimizes the operational reliability of electrical systems.

Applications:

• Industrial Applications:
  The Schneider LV432896 circuit breaker is ideal for protecting heavy machinery, large production lines, and other high-power equipment in industrial settings. Its high short-circuit withstand capacity and flexible trip unit make it perfect for safeguarding industrial electrical systems.

• Commercial Infrastructure:
  This breaker is suitable for use in large commercial buildings, including office complexes, shopping malls, and hospitals, where it ensures the safe operation of critical electrical systems such as lighting, HVAC, and power distribution.

• Motor Control Systems:
  It is well-suited for protecting motor-driven systems such as pumps, compressors, and fans. This circuit breaker ensures that motors and other electrical equipment remain safe from electrical faults and overloads, improving operational efficiency.

• Power Distribution Networks:
  In electrical distribution systems, the ComPact NSX630H ensures that circuits and equipment are adequately protected from faults, overloads, and short circuits, enhancing the reliability and stability of the entire network.

• Data Centers and Critical Infrastructure:
  In sensitive environments like data centers or telecommunications facilities, the ComPact NSX630H ensures uninterrupted operation by protecting sensitive equipment from power surges, overloads, and faults.
