. Technical Specifications Schneider LV510307

• Product Type: Circuit Breaker

• Series: Easypact CVS

• Model: CVS100B TM100D

• Poles: 3 poles (3P), designed for 3-phase electrical systems.

• Rated Current: 100 Amps

• Rated Voltage: Typically compatible with systems up to 690V.

• Trip Mechanism: TM100D trip mechanism, specifically designed for motor protection.

• Protection Type: Overload protection, short-circuit protection, and motor protection.

• Frame Size: 100A frame, ensuring the circuit breaker can handle up to 100A of current.

• Thermal Protection: Built-in thermal protection for motor protection to handle start-up and operational conditions.

• Short-Circuit Protection: Ensures rapid disconnection in case of short circuits, protecting the electrical circuit and connected equipment.

• Mounting: Designed for DIN rail mounting, making it easy to install in control panels and other electrical enclosures.

• Auxiliary Contacts: Optional auxiliary contacts for remote monitoring and control.

. Features:

• Motor Protection: The TM100D mechanism offers specialized protection for motors, ensuring protection during start-up, overloads, and faults. This makes the Easypact CVS100B ideal for motor-driven machinery.

• Compact Design: With its compact size, the Easypact CVS100B fits into smaller enclosures and control panels, optimizing space without sacrificing performance.

• Adjustable Settings: The TM100D mechanism allows for adjustable protection settings to match the specific needs of the connected motor, ensuring optimal protection for various applications.

• Overload and Short-Circuit Protection: Offers reliable overload and short-circuit protection to safeguard both the circuit breaker and the connected equipment. The breaker trips automatically in case of a fault, preventing damage to the system.

• Easy Installation and Maintenance: Designed for DIN rail mounting, the circuit breaker is easy to install and can be easily replaced or maintained in industrial environments.

• Wide Application Range: Ideal for use in industrial machinery, motor control centers (MCC), HVAC systems, pumps, and other motor-driven systems.

• Thermal-Magnetic Protection: Combines both thermal and magnetic protection for optimal security. The thermal protection prevents the motor from damage due to prolonged overloads, while the magnetic protection responds quickly to short circuits.

. Applications:

• Industrial Machinery: In industrial settings, the Easypact CVS100B TM100D circuit breaker is ideal for protecting machinery, especially motor-driven machines, from overloads and short circuits.

• Motor Control Centers (MCCs): This circuit breaker is commonly used in MCCs to protect motors and other equipment from electrical faults. It ensures a safe operation of motor-driven systems in industrial processes.

• HVAC Systems: In heating, ventilation, and air conditioning (HVAC) systems, it provides reliable protection to motors, fans, and compressors, ensuring their longevity and performance.

• Pumps and Compressors: Protects pumps and compressors in various industrial applications, offering protection against faults during start-up and in operation.

• Water Treatment Plants: In water and wastewater treatment plants, where motor-driven equipment is heavily used, this circuit breaker ensures the protection of critical machinery and continuous operation.

• Construction and Mining: In construction and mining operations, where motors are used for various heavy-duty applications, the Easypact CVS100B ensures that the motors are protected from overloads and faults.
