Schneider LV510331 | circuit breaker, EasyPact CVS100F, 36kA at 415VAC, 25A, TM-D trip unit, 3P3d

Technical Specifications:

1. Product Type: The LV510331 is a 3-pole (3P) circuit breaker, part of the EasyPact CVS100F range, providing thermal-magnetic protection with the TM-D trip unit. This model is suitable for a variety of applications where three-phase protection is required.

2. Current Rating: The circuit breaker is rated for a continuous current of 25A, making it ideal for circuits with a load of up to 25A.

3. Voltage Rating: The LV510331 circuit breaker is designed for use in 415V AC systems, offering protection for circuits operating at this voltage level. This makes it suitable for a variety of industrial and commercial electrical installations.

4. Short-Circuit Breaking Capacity: The circuit breaker is rated to handle a 36kA breaking capacity at 415V AC, ensuring that it can safely interrupt high short-circuit currents and protect the electrical circuits from damage in the event of a fault.

5. Trip Unit: The TM-D trip unit provides thermal-magnetic protection. The thermal protection handles overloads, while the magnetic protection ensures rapid response to short-circuit faults, offering reliable and instantaneous protection. This trip unit is designed to meet the needs of industrial and commercial systems, ensuring the safety of electrical circuits.

6. Number of Poles: The LV510331 is a 3-pole circuit breaker, designed for three-phase electrical systems. It can effectively protect all three phases in industrial or commercial installations, ensuring that all phases are properly safeguarded.

7. Frame Size: This circuit breaker is part of the CVS100F frame size, specifically engineered to handle a 25A rated current while ensuring that protection and operational reliability are not compromised in demanding applications.

8. Mounting: The circuit breaker is designed for DIN rail mounting, which ensures easy and secure installation in a variety of distribution panels. The mounting type is commonly used for simple integration into electrical switchgear and control panels.

9. Certification and Compliance: The LV510331 circuit breaker complies with international standards (IEC), ensuring it meets the necessary performance, safety, and quality requirements for use in electrical protection applications.

Features:

1. Thermal-Magnetic Protection (TM-D): The TM-D trip unit combines thermal protection for overload conditions and magnetic protection for short-circuit faults, providing a comprehensive protection scheme for electrical circuits.

2. High Breaking Capacity: With a 36kA breaking capacity at 415V AC, the LV510331 can safely handle and interrupt high levels of short-circuit current, ensuring that the circuit is protected from damage due to fault conditions.

3. 3-Pole Design: The 3-pole configuration provides protection for three-phase circuits, which are common in industrial and commercial environments. This ensures balanced protection for all three phases.

4. 25A Rated Current: The 25A rating makes this circuit breaker ideal for smaller systems, such as those found in light industrial or commercial environments, providing reliable protection for circuits with a 25A continuous load.

5. DIN Rail Mounting: Designed for DIN rail mounting, the LV510331 circuit breaker can be easily integrated into a wide range of electrical panels, offering quick and secure installation with minimal effort.

6. Compact and Reliable: The EasyPact CVS100F series circuit breakers are compact in size, offering high reliability in a small form factor, making them ideal for installations with space limitations.

7. Adjustable Protection Settings: The thermal settings of the TM-D trip unit can be adjusted to suit the specific protection requirements of the electrical installation, providing flexibility to meet various load conditions.
