Schneider LV510799 | circuit breaker, EasyPact CVS, CVS100B, 25kA 380/415V,TMD, 4p/4d

Technical Specifications:

• Model: EasyPact CVS100B.

• Breaking Capacity: 25 kA at 380/415 VAC (Volts alternating current).

• Rating: 100 Amperes.

• Trip Mechanism: Thermal Magnetic (TMD).

• Poles: 4 Poles (4P).

• Voltage Range: 380-415 VAC.

• Application: Designed for protecting electrical circuits in industrial, commercial, and utility applications, offering safety and efficiency in diverse environments.

Features:

1. High Breaking Capacity: The EasyPact CVS100B circuit breaker offers a breaking capacity of up to 25 kA, ensuring it can handle large short-circuit currents and protect electrical systems from damage.

2. Thermal Magnetic Protection: Equipped with a TMD trip unit, it combines both thermal and magnetic protection for optimal performance in responding to overloads and short circuits.

3. 4-Pole Design: The 4-pole configuration (4P) makes it suitable for 3-phase applications with a neutral conductor, enhancing its versatility in various electrical systems.

4. Reliable and Durable: Designed to withstand harsh environments and heavy-duty operations, making it a durable choice for demanding applications.

5. Easy Installation and Maintenance: Its user-friendly design ensures quick and easy installation, as well as straightforward maintenance procedures.

6. Voltage Compatibility: The circuit breaker operates efficiently within the 380/415 VAC voltage range, making it suitable for use in both low and medium-voltage applications.

Applications:

1. Industrial Facilities: Ideal for industrial environments where heavy machinery and large electrical systems require protection against overloads and short circuits.

2. Commercial Buildings: Used in commercial buildings to safeguard the electrical distribution systems from faults and prevent damage to critical equipment.

3. Power Distribution Networks: It is commonly used in power distribution networks to protect systems and equipment from electrical faults.

4. Motors and Large Electrical Equipment: Provides reliable protection for motors, transformers, and other large electrical equipment that require high-current protection.

5. Power Generation Stations: Can be used in power generation stations to protect the electrical systems from current surges and ensure the safety of the infrastructure.
