Schneider LV516332 | circuit breaker EasyPact CVS160F, 36 kA at 415 VAC, 125 A rating thermal magnetic TM-D trip unit, 3P 3d

Specifications Schneider LV516332

• Type: Circuit Breaker

• Model: EasyPact CVS160F

• Rated Current: 160 Amps

• Rated Voltage: 415 VAC

• Short-Circuit Breaking Capacity: 36 kA (at 415 VAC)

• Trip Unit: Thermal Magnetic TM-D (with overload and short-circuit protection)

• Poles: 3P (Three Poles)

• Design: 3d (three-phase, with adjustable protection settings)

• Protection: Overload, short-circuit, and earth fault protection

• Rated Thermal Magnetic Current: 125 A

Features Schneider LV516332

1. High Breaking Capacity:

   • The 36 kA short-circuit breaking capacity at 415 VAC ensures that the EasyPact CVS160F can handle high fault currents, making it suitable for demanding industrial and commercial environments where robust protection is required.

2. Thermal Magnetic TM-D Trip Unit:

   • The TM-D trip unit offers both thermal protection (for overloads) and magnetic protection (for short circuits). The thermal protection responds to prolonged overload conditions, while the magnetic protection acts swiftly to interrupt short-circuit faults.

3. Adjustable Protection Settings:

   • The TM-D trip unit features adjustable settings that allow fine-tuning of the protection to meet specific needs and operational conditions. This flexibility ensures that the breaker offers optimal protection for various applications.

4. Compact Design:

   • The EasyPact CVS160F is compact and designed for easy installation in tight spaces, making it ideal for applications where space-saving is crucial while still providing reliable protection.

5. Durability:

   • Built for harsh industrial environments, the circuit breaker provides long-lasting protection and can handle the wear and tear associated with heavy-duty applications.

6. Three-Pole Design:

   • The 3P (three-pole) design is perfect for three-phase electrical systems, providing balanced protection for all three phases.

7. Enhanced Safety:

   • This circuit breaker is designed to safeguard both electrical systems and personnel by reliably detecting and isolating electrical faults before they can cause damage.

Applications:

• Industrial Power Systems: Ideal for protecting machinery, control systems, and electrical distribution in factories, plants, and manufacturing environments.

• Commercial Buildings: Provides protection for electrical systems in commercial facilities, such as offices, retail spaces, and public buildings.

• Motor Protection: Suitable for use in motor circuits, where it can protect against both overloads and short circuits to ensure safe motor operation.

• Electrical Distribution Panels: Commonly used in distribution boards and electrical panels to protect circuits from faults and overloads, ensuring continuous and safe operation
