Schneider R9SCO240 | Changeover switch, Acti9, 2P, 40A, 400/415VAC

Key Specifications

• Product Type: Manual Changeover Switch

• Series: Acti9

• Number of Poles: 2P (two-pole)

• Rated Current (Ie): 40 Amps

• Rated Voltage (Ue): 400/415 V AC

• Frequency: 50/60 Hz

• Electrical Endurance: 6 kA

• Mechanical Endurance: 10,000 operating cycles

• Mounting: Suitable for DIN rail mounting

• Protection Rating: IP20 (IP40 inside an enclosure)

• Dimensions:

  • Width: 35 mm

  • Height: 85 mm

  • Depth: 44 mm

• Weight: Approximately 166 grams

• Locking Options: Padlock in ON position for safety

Features and Benefits

• Reliable Power Source Switching: The R9SCO240 allows for safe manual switching between two power sources, ensuring an uninterrupted power supply and reducing the risk of downtime.

• Compact and Space-Saving: With a narrow 35 mm width, this switch is ideal for installations where space is limited.

• High Durability: Built to last with 6,000 electrical and 10,000 mechanical operating cycles, making it a long-lasting and cost-effective solution.

• Safety Features: Equipped with a contact position indicator and a locking mechanism that prevents unauthorized switching, enhancing user safety.

• Flexible Installation: This switch can be mounted in any position, offering flexibility during installation.

• Protection Against Electrical Hazards: The IP20 protection rating ensures the switch is safe from accidental contact with live parts, providing an added layer of security.

Applications

• Residential Use: Ideal for use in homes where power source switching between different circuits or energy sources is needed.

• Commercial Buildings: Suitable for offices, retail outlets, and commercial spaces, where it ensures the continuous operation of electrical systems.

• Industrial Settings: Used in light industrial environments for controlling power supply to critical machinery and equipment.
