Schneider A9K24120 | Miniature circuit-breaker, Acti9 iK60N, 1P, 20 A, C curve, 6000 A (IEC 60898-1)
EGP 162.00
Description
Schneider A9K24120 | Miniature circuit-breaker, Acti9 iK60N, 1P, 20 A, C curve, 6000 A (IEC 60898-1)
Schneider A9K24120: Introduction
Welcome! If you’re here, you’re probably curious about the Schneider A9K24120. Whether you’re a homeowner, business owner, or just a tech enthusiast, this article will walk you through everything you need to know about this remarkable product. Let’s dive in!
What is the Schneider A9K24120?
Overview and Features
it is a high-performance miniature circuit breaker (MCB) designed for a variety of electrical systems. Known for its reliability and advanced safety features, this MCB ensures your electrical circuits are protected from overloads and short circuits.
Some standout features include:
- High breaking capacity: it can handle significant current loads without failing.
- Compact design: Its small size allows for easy installation in tight spaces.
- Enhanced safety mechanisms: It includes trip-free mechanisms and energy-limiting class features to enhance safety.
Technical Specifications
Understanding the technical specifications can help you determine if the Schneider A9K24120 is right for your needs:
- Rated current: 20A
- Number of poles: 2
- Breaking capacity: 10 kA
- Voltage rating: 240/415V AC
- Tripping curve: C curve, suitable for both residential and commercial applications.
Benefits of Using Schneider A9K24120
Reliability and Safety
One of the primary benefits of the Schneider A9K24120 is its unparalleled reliability. This MCB is engineered to function flawlessly under various conditions, ensuring your electrical systems are always protected. Its robust design minimizes the risk of electrical fires and other hazards.
Energy Efficiency
The A9K24120 is not just about safety; it also promotes energy efficiency. By preventing electrical faults, it helps reduce unnecessary energy consumption, which can translate to lower utility bills over time.
Cost-Effectiveness
While it might be tempting to opt for cheaper alternatives, the long-term savings provided by the Schneider A9K24120 make it a cost-effective choice. Its durability means fewer replacements and repairs, saving you money in the long run.
Applications of Schneider A9K24120
Residential Use
In homes, the Schneider A9K24120 is perfect for protecting circuits that power essential appliances and lighting. Its reliable performance ensures that your household electrical system remains safe and functional.
Commercial Use
For businesses, especially those with critical electrical needs, the A9K24120 provides peace of mind. It safeguards sensitive equipment from power surges and faults, which is crucial for preventing downtime and protecting investments.
Industrial Use
In industrial settings, where electrical systems are often under heavy loads, the Schneider A9K24120 stands out. Its high breaking capacity and robust construction make it ideal for protecting heavy machinery and ensuring smooth operations.
Installation Guide for Schneider A9K24120
Pre-Installation Considerations
Before installing the Schneider A9K24120, ensure you have the necessary tools and safety gear. It’s also crucial to turn off the main power supply to prevent any accidents.
Step-by-Step Installation Process
- Turn off the main power supply.
- Mount the MCB onto the DIN rail: Ensure it snaps into place securely.
- Connect the wiring: Follow the wiring diagram provided in the manual. Connect the load and supply wires correctly.
- Double-check connections: Ensure all connections are tight and secure.
- Turn on the main power supply: Test the MCB to ensure it is functioning correctly.
Post-Installation Tips
After installation, regularly check the MCB for any signs of wear or damage. Keeping it clean and free of dust can also help maintain its performance.
Maintenance Tips for Longevity
Regular Inspection
Regularly inspecting your Schneider A9K24120 can help catch any potential issues early. Look for any signs of corrosion, wear, or damage that might indicate a problem.
Troubleshooting Common Issues
If you encounter issues such as frequent tripping, it may indicate an underlying problem with your electrical system. Ensure the load does not exceed the rated capacity of the MCB, and check for any wiring issues.
Comparing Schneider A9K24120 with Competitors
Feature Comparison
When compared to other MCBs in the market, the Schneider A9K24120 stands out for its combination of compact size, high breaking capacity, and advanced safety features. It often outperforms competitors in terms of durability and reliability.
Price Comparison
While the initial cost of the Schneider A9K24120 might be higher than some competitors, its long-term benefits and lower maintenance costs make it a more economical choice in the long run.
Customer Reviews and Testimonials
Customers consistently praise the Schneider A9K24120 for its reliability and performance. Many highlight its ease of installation and the peace of mind it provides in protecting their electrical systems.
Conclusion
In conclusion, the Schneider A9K24120 is a top-tier choice for anyone looking to enhance the safety and efficiency of their electrical systems. Its robust features, coupled with the brand’s reputation for quality, make it a worthwhile investment.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Device application | Distribution |
|---|---|
| Range | Acti9 |
| Product name | Acti9 iK60 |
| Product or component type | Miniature circuit-breaker |
| Device short name | iK60N |
| Poles description | 1P |
| Number of protected poles | 1 |
| [In] rated current | 20 A at 30 °C |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Suitability for isolation | Yes conforming to EN/IEC 60898-1 |
| Standards | EN/IEC 60898-1 |
| Network frequency | 50/60 Hz |
|---|---|
| Magnetic tripping limit | 5...10 x In |
| [Ics] rated service breaking capacity | 6000 A 100 % conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz |
| Limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 440 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to EN/IEC 60898-1 |
| Contact position indicator | No |
| control type | Toggle |
| local signalling | ON/OFF indication |
| Mounting mode | Clip-on |
| mounting support | DIN rail |
| 9 mm pitches | 2 |
| height | 85 mm |
| Width | 18 mm |
| Depth | 78.5 mm |
| Net weight | 100 g |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Locking options description | Padlocking device |
| Connections - terminals | Tunnel type terminal (top or bottom) 1…25 mm² rigid Tunnel type terminal (top or bottom) 1…16 mm² flexible |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 2 N.m top or bottom |
| earth-leakage protection | Without |
| IP degree of protection | IP20 conforming to IEC 60529 |
|---|---|
| Pollution degree | 2 conforming to EN/IEC 60898-1 |
| Overvoltage category | III |
| ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7.5 cm |
| Package 1 Width | 1.8 cm |
| Package 1 Length | 9.4 cm |
| Package 1 Weight | 102 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 8.5 cm |
| Package 2 Width | 9.8 cm |
| Package 2 Length | 22 cm |
| Package 2 Weight | 1.25 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 132 |
| Package 3 Height | 30 cm |
| Package 3 Width | 30 cm |
| Package 3 Length | 40 cm |
| Package 3 Weight | 14.266 kg |
| Warranty | 18 months |
|---|
