Schneider GVAD1010 | TeSys GV2 & GV3 – auxiliary contact – 1 NO + 1 NO (fault)
Original price was: EGP 18,212.00.EGP 9,835.00Current price is: EGP 9,835.00.
Description
Schneider GVAD1010 | TeSys GV2 & GV3 – auxiliary contact – 1 NO + 1 NO (fault)
Schneider GVAD1010 | TeSys GV2 & GV3 – Auxiliary Contact – 1 NO + 1 NO (Fault)
The Schneider GVAD1010 is a reliable auxiliary contact block designed specifically for use with TeSys GV2 and GV3 motor circuit breakers. Featuring two Normally Open (1 NO + 1 NO) contacts, this unit is ideal for applications that require additional signaling or control functionalities—especially for fault indication and remote monitoring.
General Information:
-
Brand: Schneider Electric
-
Series: TeSys GV2 & GV3
-
Model Number: GVAD1010
-
Product Type: Auxiliary Contact Block
-
Contact Configuration: 1 NO (indication) + 1 NO (fault)
Key Features:
-
Double Normally Open Contacts: Offers greater flexibility in signaling, with one contact for general indication and another for fault status
-
Designed for TeSys GV2/GV3: Ensures perfect mechanical and electrical compatibility with Schneider motor circuit breakers
-
Snap-On Mounting: Quick and secure installation on the side of GV2 or GV3 devices
-
Compact and Durable: Space-saving design with robust performance in industrial settings
-
Visual Markings: Clear identification of terminals and contacts for easy wiring
Technical Specifications:
-
Contact Type: 1 NO + 1 NO
-
Rated Operational Current (Ie): Up to 10 A
-
Rated Insulation Voltage (Ui): 690 V AC
-
Conformity Standards: IEC 60947-5-1
-
Mounting Location: Side-mounted
-
Protection Rating: IP20 (finger-safe)
-
Operating Temperature: -5°C to +60°C
Applications:
-
Fault signaling in motor protection systems
-
Status feedback to control panels or PLCs
-
Auxiliary control functions in automated machinery
-
Enhancing TeSys GV motor starter functionalities
-
Alarm triggering systems for maintenance alerts
Benefits:
-
Improves operational visibility by providing dual signaling points
-
Simple integration into existing Schneider motor control solutions
-
Saves space while increasing functionality
-
Reduces installation time with tool-free snap-on design
-
Ensures safe, reliable operation in industrial environments
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | TeSys TeSys Deca |
|---|---|
| Device short name | GVAD |
| Product or component typee | Auxiliary contact block |
| Product compatibility | GV2L GV2P GV2RT GV3L GV2LE GV3P GV2ME |
| Mounting location | Left side |
| Auxiliary contacts operation | Fault signal 1 NO |
| Pole contact composition | 2 NO |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-1 300 V conforming to UL 508 300 V conforming to CSA C22.2 No 14 |
|---|---|
| [Ue] rated operational voltage | 48...690 V AC 24...240 V DC |
| [Ith] conventional free air thermal current | 6 A 2.5 A for fault signalling |
| Mechanical durability | 100000 cycles |
| Minimum switching current | 5 mA |
| Minimum switching voltage | 17 V |
| Protection type | GB2CB... circuit breaker GG fuse 10 A |
| Rated operational power in VA | 300 VA at 48 V AC-15 - electrical durability: 100000 cycles 414 VA at 690 V AC-15 - electrical durability: 100000 cycles 500 VA at 110…127 V AC-15 - electrical durability: 100000 cycles 500 VA at 500 V AC-15 - electrical durability: 100000 cycles 650 VA at 440 V AC-15 - electrical durability: 100000 cycles 720 VA at 230…240 V AC-15 - electrical durability: 100000 cycles 850 VA at 380…415 V AC-15 - electrical durability: 100000 cycles 36 VA at 24 V AC-14 - electrical durability: 1000 cycles 48 VA at 48 V AC-14 - electrical durability: 1000 cycles 72 VA at 110…127 V AC-14 - electrical durability: 1000 cycles |
| Rated operational power in W | 120 W at 240 V DC-13 - electrical durability: 100000 cycles 140 W at 110 V DC-13 - electrical durability: 100000 cycles 140 W at 24 V DC-13 - electrical durability: 100000 cycles 180 W at 60 V DC-13 - electrical durability: 100000 cycles 240 W at 48 V DC-13 - electrical durability: 100000 cycles 15 W at 48 V DC-13 - electrical durability: 1000 cycles 24 W at 24 V DC-13 - electrical durability: 1000 cycles 9 W at 60 V DC-13 - electrical durability: 1000 cycles |
| Tightening torque | 1.4 N.m - on screw clamp terminals |
| height | 89 mm |
| Width | 9.3 mm |
| Depth | 66 mm |
| Net weight | 0.055 kg |
| Colour | Dark grey |
| Environmental characteristic | Normal environment |
|---|---|
| product certifications | UKCA |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.500 cm |
| Package 1 Width | 6.500 cm |
| Package 1 Length | 8.700 cm |
| Package 1 Weight | 42.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 9.500 cm |
| Package 2 Width | 10.000 cm |
| Package 2 Length | 15.000 cm |
| Package 2 Weight | 470.000 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 60 |
| Package 3 Height | 15.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 3.104 kg |
| Warranty | 18 months |
|---|
