Schneider LR9G115 | Electronic thermal overload relay,TeSys Giga,28-115 A,class 5E-30E,push-in control connection

The Schneider LR9G115 is an advanced electronic thermal overload relay from the TeSys Giga series, designed to provide precise and reliable protection for motors and electrical circuits against thermal overloads. With a current range of 28 to 115 A and a class 5E-30E time delay, this electronic relay offers enhanced flexibility and accuracy in motor protection. The LR9G115 is built to ensure the efficient operation of industrial and commercial motor control systems, offering push-in control connections for easy installation.

Technical Specifications

Here are the key technical specifications for the LR9G115 electronic thermal overload relay:

• Model: LR9G115
• Brand: Schneider Electric
• Type: Electronic Thermal Overload Relay
• Current Range: 28 to 115 A
• Time Delay Class: Class 5E-30E
• Control Connection: Push-in connection for ease of installation
• Mounting: Designed for easy integration with TeSys Giga contactors
• Voltage Rating: Suitable for 3-phase AC motors
• Adjustment: Adjustable settings to match the specific motor protection requirements
• Features: Includes a digital display for easy setting and monitoring of protection parameters

Key Features

The Schneider LR9G115 electronic thermal overload relay is equipped with several key features that make it a standout choice for motor protection:

1. Precise Protection – Provides accurate protection against thermal overload by continuously monitoring the motor’s current and temperature.
2. Wide Current Range – With a range of 28 to 115 A, it is suitable for a variety of motor sizes and industrial applications.
3. Class 5E-30E Time Delay – The relay features an adjustable time delay class, providing flexibility for different operational conditions and ensuring reliable motor protection.
4. Push-In Control Connection – Allows for quick and secure installation with push-in technology, simplifying wiring and reducing installation time.
5. Digital Display – The built-in digital display makes it easy to monitor settings and adjust the relay according to specific protection needs.
6. Durability and Reliability – Designed to withstand demanding industrial environments, ensuring long-lasting protection even under harsh conditions.
7. Enhanced Safety – Prevents motor overheating and potential damage caused by overcurrent conditions, reducing the risk of equipment failure and downtime.


   Applications

   The LR9G115 electronic thermal overload relay is ideal for protecting motors and electrical equipment in a wide range of industrial and commercial applications:

   1. Motor Protection – Provides thermal overload protection for motors, ensuring reliable operation and preventing damage from sustained overcurrent conditions.
   2. Industrial Machinery – Used in various industrial machines and systems to safeguard motors and prevent downtime caused by overloads.
   3. Pumps and Compressors – Protects motors in pumps and compressors, ensuring the safe and efficient operation of these critical systems.
   4. HVAC Systems – Ideal for use in heating, ventilation, and air conditioning systems, offering protection for motors in these energy-intensive applications.
   5. Conveyor Systems – Ensures the protection of motors in conveyor systems, preventing failure and minimizing maintenance costs.
   6. Automation Systems – Applied in automated industrial systems, offering motor protection to ensure continuous and smooth operation of machinery.
