Schneider LV510797 | circuit breaker, EasyPact CVS, CVS100B, 25kA 380/415V,TMD, 4p/4d
Schneider LV510797 | circuit breaker, EasyPact CVS, CVS100B, 25kA 380/415V,TMD, 4p/4d
Original price was: EGP 1,396,500.00.EGP 830,918.00Current price is: EGP 830,918.00.
Description
Schneider LV510797 | circuit breaker, EasyPact CVS, CVS100B, 25kA 380/415V,TMD, 4p/4d
Technical Specifications:
-
Rated Current (In): Adjustable from 25A to 100A
-
Breaking Capacity: 25 kA at 415V
-
Protection Mechanism: Built-in thermal-magnetic protection (TMD)
-
Number of Poles: 4 (suitable for three-phase systems with neutral)
-
Mounting Type: Panel mounting
-
Protection Class: IP40 (when installed inside an enclosure)
-
Compliance Standards: IEC 60947-2
Key Features:
-
Compact design to save space in distribution panels
-
Dual protection against overload and short circuit
-
Adjustable thermal and magnetic settings for flexibility
-
Reliable safety and performance with Schneider Electric technology
-
Ideal for both industrial and commercial applications
Common Applications:
-
Circuit protection in industrial plants and factories
-
Power distribution in commercial buildings
-
Sub-distribution panels in medium-voltage power systems
-
Generator or main feeder protection in electrical networks
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS100...250 |
| Product name | EasyPact CVS |
| Device short name | CVS100B |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| poles description | 4P |
| Protected poles description | 4D |
| Earth leakage protection (Vigi add on) | Without |
| [In] rated current | 63 A at 50 °C |
| Network type | AC |
| Utilisation category | Category A |
| [Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 63 A at 50 °C |
| Protection type | Overload protection (thermal) Short-circuit protection (magnetic) |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
|---|---|
| Network frequency | 50/60 Hz |
| Breaking capacity code | B |
| [Ics] rated service breaking capacity | 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Neutral position | Left |
| Mechanical durability | 30000 cycles |
| Electrical durability | 12000 cycles 415 V In conforming to IEC 60947-2 |
| Control type | Toggle |
| Neutral protection setting | 1 x Ir (4D) |
| Long time pick-up adjustment type Ir | Adjustable |
| Long time pick-up adjustment range | 0.7...1 x In |
| Long time delay adjustment type | Fixed |
| Short-time delay adjustment type | Fixed |
| Instantaneous pick-up adjustment type Ii | Fixed |
| instantaneous pick-up adjustment range | 500 A |
| Contact position indicator | Yes |
| Mounting support | Backplate |
| Mounting mode | Fixed |
| Upside connection | Front |
| downside connection | Front |
| Connection pitch | 35 mm |
| Compatibility code | CVS100 |
| Width | 140 mm |
| Depth | 86 mm |
| Height | 161 mm |
| Net weight | 1.9 kg |
| Standards | IEC 60947-2 EN 60947-2 |
|---|---|
| Product certifications | GOST IEC |
| Electrical shock protection class | Class II |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 2.209 kg |
