Schneider LV525608 | circuit breaker, EasyPact CVS, CVS250B , 25kA 380/415V,TMD, 3p/3d
Exceptional reliability and safety – Schneider Electric quality ensures consistent protection of equipment and personnel.
High performance-to-cost ratio – delivers professional-grade protection at an economical price point.
Compact and easy installation – ideal for panel builders and retrofit applications with limited space.
Flexible protection settings – thermal adjustment options allow fine-tuning according to load requirements.
Durable and low-maintenance – built for long-term performance with minimal servicing needs.
Description
Schneider LV525608 | circuit breaker, EasyPact CVS, CVS250B , 25kA 380/415V,TMD, 3p/3d
Description
The Schneider Electric EasyPact CVS250B is a 3-pole molded case circuit breaker (MCCB) designed for reliable protection of low-voltage electrical distribution systems in commercial, industrial, and residential applications. It provides both overload and short-circuit protection through a built-in Thermal-Magnetic (TMD) trip unit.
This model offers a breaking capacity of 25 kA at 380/415 V AC, ensuring dependable protection even under high fault-current conditions. With its fixed-mounted design, compact size, and robust performance, the CVS250B is ideal for main or sub-distribution panels in medium-sized installations.
Built under IEC 60947-2 standards, it ensures consistent performance, durability, and safety in demanding environments.
Technical Specifications (Overview)
Model: EasyPact CVS250B
Part number: LV525608
Number of poles: 3 poles (3P/3d)
Rated current (In): 250 A at 40 °C
Rated operational voltage (Ue): up to 415 V AC (50/60 Hz)
Breaking capacity (Icu): 25 kA at 380/415 V AC
Trip unit type: Thermal-Magnetic (TM-D)
Mounting type: Fixed mounting, front connection (top and bottom)
Degree of protection: IP40 (front face)
Operating temperature range: –25 °C to +70 °C
Standards compliance: IEC 60947-2 / EN 60947-2
Applications
Protection of electrical distribution circuits in industrial plants, commercial buildings, and public infrastructure.
Suitable for low-voltage three-phase distribution systems (typically 380/415 V).
Used as a main circuit breaker or feeder protection in switchboards and control panels.
Ideal for installations that require a high breaking capacity in a compact form.
Applicable in fixed-type panels where draw-out functionality is not required.
Key Features
High breaking capacity of 25 kA ensures strong protection against heavy fault currents.
Thermal-Magnetic (TM-D) trip unit provides reliable overload and short-circuit protection.
Compact and robust design enables easy integration in various panel layouts.
Front connection terminals simplify wiring and maintenance operations.
Wide operating temperature range allows performance stability in harsh conditions.
Globally certified to IEC standards for safe use worldwide.
Additional information
| brand | Schneider Electric |
|---|
Specifications
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS100...250 |
| Product name | EasyPact CVS |
| Device short name | CVS250B |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| Poles description | 3P |
| Protected poles description | 3D |
| Earth leakage protection (Vigi add on) | Without |
| [In] rated current | 250 A at 50 °C |
| Network type | AC |
| Utilisation category | Category A |
| [Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 250 A at 40 °C |
| Protection type | Short-circuit protection (magnetic) Overload protection (thermal) |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
|---|---|
| Network frequency | 50/60 Hz |
| Breaking capacity code | B |
| [Ics] rated service breaking capacity | 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles 415 V In conforming to IEC 60947-2 |
| Control type | Toggle |
| Long time pick-up adjustment type Ir | Adjustable |
| Long time pick-up adjustment range | 0.7...1 x In |
| Long time delay adjustment type | Fixed |
| Short-time delay adjustment type | Fixed |
| Instantaneous pick-up adjustment type Ii | Fixed |
| Instantaneous pick-up adjustment range | 2500 A |
| Contact position indicator | Yes |
| Mounting support | Backplate |
| Mounting mode | Fixed |
| Upside connection | Front |
| Downside connection | Front |
| Connection pitch | 35 mm |
| Compatibility code | CVS250 |
| Width | 105 mm |
| Depth | 86 mm |
| Height | 161 mm |
| Net weight | 1.7 kg |
| Standards | IEC 60947-2 EN 60947-2 |
|---|---|
| Product certifications | IEC GOST |
| Electrical shock protection class | Class II |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 2.209 kg |
