Schneider A9N61503 | miniature circuit breaker – C60H – 1 pole – 3 A – C curve

Technical Specifications A9N61503

• Product Reference: A9N61503

• Product Series: Acti9 C60H

• Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current (In): 3 A

• Tripping Curve: C Curve (trips between 5–10 × rated current)

• Breaking Capacity: Up to 6 kA (as per IEC/EN 60898-1)

• Rated Operational Voltage: 230/400 V AC

• Frequency: 50/60 Hz

• Mounting: DIN rail, modular design

• Terminal Type: Screw terminals (top and bottom)

• Degree of Protection: IP20 (when installed in enclosure)

• Standards:

  • IEC/EN 60898-1

  • IEC/EN 60947-2

Key Features:

• Precise Protection at 3 A
  Suitable for low-current circuits with moderate startup currents.

• C Curve Performance
  Ideal for general-purpose loads like lighting, small motors, and control devices.

• Modular & Space-Saving Design
  Compact form factor for optimized panel layout.

• Reliable and Durable
  Built to Schneider Electric’s high quality and safety standards.

• Ease of Installation
  Fast clip-on mounting with secure terminal connections.

• Global Certification
  Conforms to leading international standards for safety and performance.

Applications:

• Control and Instrumentation Circuits
  Protects low-load components in industrial and automation systems.

• Lighting Systems
  Suitable for small lighting circuits in residential and commercial buildings.

• Electrical Panels and Distribution Boards
  Used to protect individual circuits or devices with low current requirements.

• Security and Monitoring Systems
  Protects power lines for cameras, sensors, or communication modules.

• Office and Home Installations
  Ideal for circuits dedicated to sensitive or low-power electronics.
