Schneider GV2ME08| Motor circuit breaker, TeSys GV2, 3P, 2.5-4 A, thermal magnetic, screw clamp terminals
Schneider GV2ME08| Motor circuit breaker, TeSys GV2, 3P, 2.5-4 A, thermal magnetic, screw clamp terminals
Original price was: EGP 52,326.00.EGP 28,257.00Current price is: EGP 28,257.00.
Description
Schneider GV2ME08: A Comprehensive Guide
Introduction
it is a versatile and efficient motor circuit breaker, essential for protecting motors in various applications. This guide will provide an in-depth look at its features, specifications, installation process, and much more, helping you understand why it’s a valuable component in any electrical system.
What is the Schneider GV2ME08?
The Schneider GV2ME08 is a motor circuit breaker designed to protect motors from overloads, short circuits, and phase failures. It is part of the GV2 series, known for its reliability and efficiency.
General Description
it offers robust protection for motors, ensuring they operate safely and efficiently. It is built to handle demanding environments and provides consistent performance over time.
Key Specifications
- Voltage Rating: Up to 690V AC
- Current Rating: 2.5-4A
- Breaking Capacity: 100 kA at 400V AC
- Trip Class: 10A
Intended Applications
it is suitable for various applications, including industrial machinery, HVAC systems, and commercial equipment.
Features of Schneider GV2ME08
it is packed with features that enhance its performance and reliability.
High Performance
Designed to handle a range of motor protection needs, it ensures reliable operation and protection against electrical faults.
Compact Design
Its compact size allows for easy integration into control panels and tight spaces without compromising on performance.
Safety Features
it includes features like thermal-magnetic protection and manual reset options, enhancing safety and preventing damage to motors.
Technical Specifications
Understanding the technical specifications of the Schneider GV2ME08 is crucial for proper application and installation.
Voltage Ratings
The GV2ME08 operates efficiently at voltages up to 690V AC, making it versatile for various electrical systems.
Current Capacity
With a current rating of 2.5-4A, it can protect motors within this range, ensuring they operate within safe limits.
Operating Temperature Range
The operating temperature range of -20°C to 60°C allows the GV2ME08 to function effectively in diverse environmental conditions.
Installation and Setup
Proper installation is essential for the optimal performance of the Schneider GV2ME08.
Pre-installation Requirements
Before installation, ensure all necessary tools and safety equipment are available, and that the electrical system is properly prepared.
Step-by-step Installation Guide
- Turn off Power: Ensure the power supply is completely shut off to prevent any electrical hazards.
- Mount the Breaker: Securely mount the GV2ME08 in the designated location using appropriate hardware.
- Connect Wires: Carefully connect the wires to the breaker terminals, following the wiring diagram.
- Check Connections: Double-check all connections to ensure they are secure and correctly placed.
- Restore Power: Turn the power back on and test the breaker to ensure it is functioning correctly.
Safety Precautions During Installation
Always follow safety guidelines, wear appropriate protective gear, and ensure the work area is free of hazards to prevent accidents during installation.
Comparing Schneider GV2ME08 with Other Models
Understanding the differences between the Schneider GV2ME08 and other models can help in selecting the right motor circuit breaker for specific needs.
Schneider GV2ME08 vs. GV2ME07
- Current Capacity: The GV2ME08 has a higher current capacity range (2.5-4A) compared to the GV2ME07 (1.6-2.5A).
- Applications: The GV2ME08 is more suited for slightly higher power motors, whereas the GV2ME07 is ideal for lower power motors.
Schneider GV2ME08 vs. GV2ME10
- Current Capacity: The GV2ME10 offers a higher current range (4-6.3A), making it suitable for more powerful motors.
- Performance: Both models offer similar performance, but the choice depends on the specific motor requirements.
Benefits of Choosing Schneider GV2ME08
The Schneider GV2ME08 stands out for its reliable performance, robust design, and effective protection features, making it a preferred choice for many applications.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | TeSys Deca |
|---|---|
| Product name | TeSys GV2 TeSys Deca |
| product or component type | Motor circuit breaker |
| Device short name | GV2ME |
| Device application | Motor protection |
| Trip unit technology | Thermal-magnetic |
| poles description | 3P |
|---|---|
| Network type | AC |
| Utilisation category | Category A conforming to IEC 60947-2 AC-3 conforming to IEC 60947-4-1 AC-3e conforming to IEC 60947-4-1 |
| Network frequency | 50/60 Hz conforming to IEC 60947-4-1 |
| Fixing mode | 35 mm symmetrical DIN rail: clipped Panel: screwed (with adaptor plate) |
| Motor power kW | 1.1 kW at 400/415 V AC 50/60 Hz 1.5 kW at 400/415 V AC 50/60 Hz 1.5 kW at 500 V AC 50/60 Hz 2.2 kW at 500 V AC 50/60 Hz 3 kW at 690 V AC 50/60 Hz 2.2 kW at 690 V AC 50/60 Hz |
| Breaking capacity | 100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 100 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 100 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 100 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 3 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ics] rated service short-circuit breaking capacity | 100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 75 % at 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| Control type | Push-button |
| [In] rated current | 4 A |
| Thermal protection adjustment range | 2.5…4 A conforming to IEC 60947-4-1 |
| Magnetic tripping current | 51 A |
| [Ith] conventional free air thermal current | 4 A conforming to IEC 60947-4-1 |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Phase failure sensitivity | Yes conforming to IEC 60947-4-1 |
| Suitability for isolation | Yes conforming to IEC 60947-1 § 7-1-6 |
| Power dissipation per pole | 2.5 W |
| Mechanical durability | 100000 cycles |
| Electrical durability | 100000 cycles for AC-3 at 415 V In 100000 cycles for AC-3e at 415 V In |
| Rated duty | Continuous conforming to IEC 60947-4-1 |
| Tightening torque | 1.7 N.m - on screw clamp terminal |
| Width | 45 mm |
| Height | 89 mm |
| Depth | 78.5 mm |
| net weight | 0.26 kg |
| Colour | Dark grey |
| Standards | EN/IEC 60947-2 EN/IEC 60947-4-1 |
|---|---|
| Product certifications | CCC UL CSA EAC ATEX LROS (Lloyds register of shipping) BV RINA DNV-GL UKCA |
| IK degree of protection | IK04 |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Climatic withstand | Conforming to IACS E10 |
| ambient air temperature for storage | -40…80 °C |
| Fire resistance | 960 °C conforming to IEC 60695-2-11 |
| Ambient air temperature for operation | -20…60 °C |
| Mechanical robustness | Shocks: 30 Gn for 11 ms Vibrations: 5 Gn, 5...150 Hz |
| Operating altitude | 2000 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.800 cm |
| Package 1 Width | 8.500 cm |
| Package 1 Length | 9.300 cm |
| Package 1 Weight | 253.000 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 6.414 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 384 |
| Package 3 Height | 75.000 cm |
| Package 3 Width | 60.000 cm |
| Package 3 Length | 80.000 cm |
| Package 3 Weight | 109.232 kg |
| Warranty | 18 months |
|---|
