Schneider GVAD0110 | TeSys GV2 & GV3 – auxiliary contact – 1 NO + 1 NC (fault)
Original price was: EGP 18,212.00.EGP 9,835.00Current price is: EGP 9,835.00.
Description
Schneider GVAD0110 | TeSys GV2 & GV3 – auxiliary contact – 1 NO + 1 NC (fault)
Schneider GVAD0110 | TeSys GV2 & GV3 – Auxiliary Contact – 1 NO + 1 NC (Fault)
The Schneider GVAD0110 is an auxiliary contact block designed for use with TeSys GV2 and GV3 motor starters and circuit breakers. This component provides additional contacts for fault signaling, making it essential for monitoring and control systems in industrial applications.
General Information:
-
Brand: Schneider Electric
-
Series: TeSys GV2 & GV3
-
Model Number: GVAD0110
-
Product Type: Auxiliary contact block
-
Contact Configuration: 1 NO (Normally Open) + 1 NC (Normally Closed)
-
Purpose: Fault signaling and control applications
Key Features:
-
Dual Contact Configuration: Includes one Normally Open (NO) and one Normally Closed (NC) contact, providing both signaling and control flexibility
-
Compatibility: Designed to work seamlessly with TeSys GV2 and GV3 motor starters and circuit breakers
-
Fault Indication: Ideal for fault detection and signaling in motor control and protection systems
-
Compact Design: Easily mounts onto TeSys GV2 or GV3 units for space-saving installation
-
Reliable Operation: Ensures dependable performance in critical applications
Technical Specifications:
-
Contact Configuration: 1 NO + 1 NC
-
Rated Current: 10 A
-
Rated Voltage: 690 V AC
-
Operating Temperature Range: -5°C to +60°C
-
Standards Compliance: IEC 60947-5-1
-
Mounting: Snap-on to TeSys GV2 & GV3 units
-
IP Rating: IP20 for protection against touch
Applications:
-
Fault signaling in motor control systems
-
Auxiliary control circuits in industrial automation
-
Status monitoring in motor starters and circuit breakers
-
Fault detection in equipment protection systems
-
Alarm systems in electrical panels
Benefits:
-
Enhances motor and circuit breaker monitoring by adding fault signaling capability
-
Provides reliable operation with dual contact configuration for flexible use
-
Easy integration with TeSys GV2 & GV3 products
-
Reduces system downtime by enabling quick fault detection
-
Supports compliance with international electrical standards
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | TeSys TeSys Deca |
|---|---|
| Device short name | GVAD |
| Product or component type | Auxiliary contact block |
| Product compatibility | GV2ME GV2L GV3P GV2P GV3L GV2LE GV2RT |
| Mounting location | Left side |
| Auxiliary contacts operation | Fault signal 1 NC |
| Pole contact composition | 1 NO + 1 NC |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-1 300 V conforming to UL 508 300 V conforming to CSA C22.2 No 14 |
|---|---|
| [Ue] rated operational voltage | 48...690 V AC 24...240 V DC |
| [Ith] conventional free air thermal current | 6 A 2.5 A for fault signalling |
| Mechanical durability | 100000 cycles |
| Minimum switching current | 5 mA |
| Minimum switching voltage | 17 V |
| Protection type | GB2CB... circuit breaker GG fuse 10 A |
| Rated operational power in VA | 300 VA at 48 V AC-15 - electrical durability: 100000 cycles 414 VA at 690 V AC-15 - electrical durability: 100000 cycles 500 VA at 110…127 V AC-15 - electrical durability: 100000 cycles 500 VA at 500 V AC-15 - electrical durability: 100000 cycles 650 VA at 440 V AC-15 - electrical durability: 100000 cycles 720 VA at 230…240 V AC-15 - electrical durability: 100000 cycles 850 VA at 380…415 V AC-15 - electrical durability: 100000 cycles 36 VA at 24 V AC-14 - electrical durability: 1000 cycles 48 VA at 48 V AC-14 - electrical durability: 1000 cycles 72 VA at 110…127 V AC-14 - electrical durability: 1000 cycles |
| Rated operational power in W | 120 W at 240 V DC-13 - electrical durability: 100000 cycles 140 W at 110 V DC-13 - electrical durability: 100000 cycles 140 W at 24 V DC-13 - electrical durability: 100000 cycles 180 W at 60 V DC-13 - electrical durability: 100000 cycles 240 W at 48 V DC-13 - electrical durability: 100000 cycles 15 W at 48 V DC-13 - electrical durability: 1000 cycles 24 W at 24 V DC-13 - electrical durability: 1000 cycles 9 W at 60 V DC-13 - electrical durability: 1000 cycles |
| Tightening torque | 1.4 N.m - on screw clamp terminals |
| height | 89 mm |
| Width | 9.3 mm |
| Depth | 66 mm |
| Net weight | 0.055 kg |
| Colour | Dark grey |
| Environmental characteristic | Normal environment |
|---|---|
| product certifications | UKCA |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.700 cm |
| Package 1 Width | 1.500 cm |
| Package 1 Length | 6.600 cm |
| Package 1 Weight | 47.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 9.500 cm |
| Package 2 Width | 15.000 cm |
| Package 2 Length | 10.000 cm |
| Package 2 Weight | 500.000 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 60 |
| Package 3 Height | 15.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 3.380 kg |
| Warranty | 18 months |
|---|
