Schneider LV540505. | circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 3P 3d
Schneider LV540505. | circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 3P 3d
Original price was: EGP 3,440,520.00.EGP 2,047,109.00Current price is: EGP 2,047,109.00.
Description
Schneider LV540505. | circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 3P 3d
Technical Specifications:
-
Model: EasyPact CVS400F.
-
Breaking Capacity: 36 kA at 415 VAC (Volts alternating current).
-
Rating: 400 Amperes.
-
Electronic Trip Unit: ETS 2.3.
-
Poles: 3 Poles (3P).
-
Technology: Utilizes advanced electronic trip technology for fast and accurate fault response.
-
Voltage: 415 VAC.
-
Application: Designed for protecting circuits from overloads, short circuits, and other electrical faults, ensuring the safety of electrical systems.
Features:
-
High Performance: The EasyPact CVS400F circuit breaker offers a breaking capacity of up to 36 kA, making it capable of handling high loads and short circuit currents effectively.
-
Reliable Design: The design ensures effective protection against electrical faults, minimizing the risk of damage to equipment and machinery.
-
Advanced Technology: The ETS 2.3 electronic trip unit ensures quick, accurate response to faults, enhancing the protection of your electrical system.
-
Multiple Protection: The circuit breaker provides comprehensive protection against overloads, short circuits, and earth faults, ensuring overall system security.
-
Energy Efficiency: It helps maintain energy efficiency in electrical systems by offering reliable protection with minimal energy consumption.
-
Ease of Installation and Maintenance: The breaker’s design facilitates easy installation and maintenance, saving time and effort for users.
Applications:
-
Industrial Facilities: The Schneider LV540505 is ideal for use in factories and industrial facilities that require robust, fault-protected electrical systems.
-
Commercial Buildings: It is commonly used in commercial buildings such as offices and retail stores to protect electrical systems from critical faults.
-
Power Generation Stations: The circuit breaker is highly suitable for power generation plants where the electrical system requires protection against sudden current surges.
-
Large Electrical Equipment: It is used to protect large electrical equipment such as motors and heavy industrial machinery that require high-current protection.
-
Power Distribution Systems: The breaker offers protection for power distribution systems that supply multiple electrical devices, ensuring safe operation.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | EasyPact |
|---|---|
| Range of product | EasyPact CVS400...630 |
| Product name | EasyPact CVS |
| Device short name | CVS400F |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| poles description | 3P |
| Protected poles description | 3D |
| Earth leakage protection (Vigi add on) | Without |
| [In] rated current | 400 A at 40 °C |
| Network type | AC |
| Utilisation category | Category A |
| [Icu] Breaking capacity | 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Trip unit name | ETS 2.3 |
| Trip unit technology | Electronic |
| Trip unit rating | 400 A at 40 °C |
| Protection type | Instantaneous short-circuit protection Overload protection (long time) Short time short-circuit protection |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to EN/IEC 60947-2 |
|---|---|
| Network frequency | 50/60 Hz |
| Breaking capacity code | F |
| [Ics] rated service breaking capacity | 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 23 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 15000 cycles |
| Electrical durability | 6000 cycles 415 V In conforming to IEC 60947-2 |
| Trip unit protection functions | LSoI |
| Control type | Toggle |
| Long time pick-up adjustment type Ir | Adjustable 9 settings |
| Long time pick-up adjustment range | 160…400 A |
| Long time delay adjustment type | Fixed |
| [tr] long-time delay adjustment range | 5.5 s at 7.2 x Ir 8 s at 6 x Ir 200 s at 1.5 x Ir |
| thermal memory | Yes |
| Short-time pick-up adjustment type Isd | Adjustable 9 settings |
| [Isd] short-time pick-up adjustment range | 1.5...10 x Ir |
| Short-time delay adjustment type | Fixed |
| Instantaneous pick-up adjustment type Ii | Fixed |
| instantaneous pick-up adjustment range | 11 x In |
| Contact position indicator | Yes |
| Mounting support | Backplate |
| Mounting mode | Fixed |
| Upside connection | Front |
| downside connection | Front |
| Connections - terminals | Screw connection |
| Connection pitch | 45 mm |
| Compatibility code | CVS400 |
| Width | 140 mm |
| Depth | 110 mm |
| Height | 255 mm |
| Net weight | 4.7 kg |
| Standards | EN 60947-2 IEC 60947-2 |
|---|---|
| Product certifications | IEC GOST |
| Electrical shock protection class | Class II |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 15.5 cm |
| Package 1 Width | 15.2 cm |
| Package 1 Length | 28.8 cm |
| Package 1 Weight | 5.16 kg |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 3 |
| Package 2 Height | 23.9 cm |
| Package 2 Width | 37.402 cm |
| Package 2 Length | 49.612 cm |
| Package 2 Weight | 16.963 kg |
| Unit Type of Package 3 | PAL |
| Number of Units in Package 3 | 48 |
| Package 3 Height | 90.0 cm |
| Package 3 Width | 80.0 cm |
| Package 3 Length | 120.0 cm |
| Package 3 Weight | 282840.0 g |
