Schneider GZ1AN20 | Auxiliary Contact Block, EasyPact GZ1, 2NO, Left-Side Mounting

1. Introduction

The Schneider GZ1AN20 is an auxiliary contact block designed for use with EasyPact GZ1 motor circuit breakers. It provides additional switching capabilities for control circuits, enhancing the functionality of the main breaker. The 2NO (2 Normally Open) contacts allow seamless integration into industrial control systems.

2. Key Features

• 2NO (Normally Open) Contacts – Enables additional circuit control functions

• Left-Side Mounting – Designed for easy attachment to EasyPact GZ1 motor circuit breakers

• Compact & Durable Design – Optimized for industrial environments

• Snap-On Installation – No extra tools required for assembly

• Reliable Performance – Ensures stable electrical connections

• Enhanced Safety & Control – Expands functionality of motor protection systems

3. Technical Specifications

• Product Series: EasyPact GZ1

• Number of Contacts: 2NO

• Mounting Position: Left-hand side

• Electrical Rating: Suitable for low-voltage control applications

• Compatibility: Designed for EasyPact GZ1 motor circuit breakers

• Installation Method: Snap-on attachment

• Operating Temperature: -25°C to +55°C

• Compliance Standards: IEC 60947-5-1

4. Applications

The Schneider GZ1AN20 auxiliary contact block is ideal for:

• Motor Control & Protection Systems – Enhances control panel functionality

• Automation & Industrial Processes – Enables status monitoring and remote operation

• Safety & Alarm Circuits – Helps in fault indication and shutdown mechanisms

• Electrical Distribution Panels – Adds additional switching capability

5. Benefits

• Enhanced Control Flexibility – Allows for additional command and signaling functions

• Quick & Easy Installation – Reduces assembly time with tool-free mounting

• Improved System Monitoring – Helps in real-time tracking of motor circuit breaker status

• Reliable & Durable – Built for long-term industrial use

• Seamless Integration – Compatible with EasyPact GZ1 motor circuit breakers
