Schneider LA1KN31 TeSys K: A Comprehensive Guide
Introduction to Schneider LA1KN31 TeSys K
In the realm of industrial and commercial electrical solutions, the name Schneider Electric stands out for its innovation and reliability. One of the standout products in its lineup is the Schneider LA1KN31 TeSys K. This article delves into the intricacies of this remarkable device, exploring its features, applications, benefits, and more.
Understanding TeSys K Series
Overview of TeSys K
The TeSys K series is renowned for its robustness and versatility. It encompasses a range of products designed to meet the diverse needs of industrial and commercial users.
Features of TeSys K
TeSys K devices are characterized by their advanced functionality, durability, and safety features. They are engineered to deliver optimal performance in demanding environments.
LA1KN31: An Overview
Introduction
it is a vital component of the TeSys K series, offering unparalleled control and protection for electrical systems. It serves as a crucial link between the control circuit and the power circuit, ensuring seamless operation.
Key Specifications
it is equipped with a range of features that make it ideal for various applications. These include high switching capacity, compact design, and compatibility with a wide range of accessories.
Applications of LA1KN31
Industrial Applications
it finds widespread use in industrial settings, where it plays a critical role in controlling motors, pumps, and other electrical equipment. Its reliability and efficiency make it indispensable in manufacturing facilities, warehouses, and production plants.
Commercial Applications
In commercial environments such as office buildings, retail stores, and healthcare facilities, the LA1KN31 provides reliable control and protection for lighting, HVAC systems, and other essential infrastructure.
Benefits of Using LA1KN31
Efficiency and Reliability
One of the primary advantages of it is its efficiency in controlling electrical systems. It ensures smooth operation while minimizing downtime and maintenance costs.
Cost-Effectiveness
Despite its advanced features, it remains highly cost-effective, offering exceptional value for money. Its durable construction and long service life contribute to significant savings over time.
Installation and Setup
Installation Process
Installing it is straightforward, thanks to its user-friendly design and comprehensive installation instructions. It can be easily integrated into existing electrical systems with minimal disruption.
Setup and Configuration
Once installed, it can be quickly configured to meet specific requirements. Its intuitive interface allows users to customize settings and parameters with ease.
Additional information
| brands | Schneider Electric |
|---|
Specifications
| Range | TeSys |
|---|---|
| Product name | TeSys K |
| Product or component type | Auxiliary contact block |
| Device short name | LA1 |
| Range compatibility | TeSys K LC1K TeSys K CA2K TeSys K CA3K |
| Mounting location | Front |
| Pole contact composition | 3 NO + 1 NC |
| Contacts operation | Instantaneous |
| [Ue] rated operational voltage | 690 V AC 25...400 Hz |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-5-1 600 V conforming to UL 60947-5-1 600 V conforming to CSA C22.2 No 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A (at 50 °C) |
| Standards | EN/IEC 60947-5-1 UL 60947-5-1 CSA C22.2 No 60947-5-1 GB/T 14048.5 JIS C8201-5-1 UL 60335-2-40:Annex JJ |
| Product certifications | CB Scheme CCC UL CSA CE UKCA |
| Irms rated making capacity | 110 A at <= 690 V AC conforming to IEC 60947 |
|---|---|
| Permissible short-time rating | 80 A 1 s 60 A 500 ms 110 A 100 ms |
| Associated fuse rating | 10 A gG at <= 690 V conforming to IEC 60947 |
| Minimum switching current | 5 mA |
| Minimum switching voltage | 17 V |
| Non overlap distance | 0.5 mm |
| Insulation resistance | > 10 MOhm |
| Connections - terminals | Screw clamp terminals 1 cable(s) 0.34…1.5 mm²flexible with cable end Screw clamp terminals 1 cable(s) 0.75…4 mm²flexible without cable end Screw clamp terminals 1 cable(s) 1.5…4 mm²rigid Screw clamp terminals 2 cable(s) 0.34…1.5 mm²flexible with cable end Screw clamp terminals 2 cable(s) 0.75…4 mm²flexible without cable end Screw clamp terminals 2 cable(s) 1.5…4 mm²rigid |
| Tightening torque | 1.3 N.m - with screwdriver Philips No 2 1.3 N.m - with screwdriver pozidriv No 2 |
| Height | 30 mm |
| Width | 38 mm |
| Depth | 35 mm |
| Net weight | 0.045 kg |
| Environmental characteristic | Normal environment |
|---|---|
| IP degree of protection | IP20 conforming to IEC 60529 |
| Protective treatment | TC conforming to IEC 60068 |
| Ambient air temperature for storage | -50…80 °C |
| Ambient air temperature for operation | -25…50 °C |
| Operating altitude | 2000 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.8 cm |
| Package 1 Width | 3.6 cm |
| Package 1 Length | 4 cm |
| Package 1 Weight | 41 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 3 cm |
| Package 2 Width | 14 cm |
| Package 2 Length | 13 cm |
| Package 2 Weight | 410 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 100 |
| Package 3 Height | 15 cm |
| Package 3 Width | 30 cm |
| Package 3 Length | 40 cm |
| Package 3 Weight | 4.1 kg |
| Warranty | 18 |
|---|
